Install the head.
•
Pretighten the six nuts on the stud bolts
proceeding in the following order: 1 - 2
- 3 - 4 - 5 - 6.
•
Then tighten them fully following the
same order.
•
Tighten the two screws according to
the sequence (a - b)
•
Install the camshaft control gear con-
nected with a clamp to the timing chain.
•
Keep the gear in position with the chain
tightened.
THE SIDE WITH THE BEVELLED HOLE IN THE TIMING
SYSTEM GEAR MUST ALWAYS FACE THE EXTERIOR OF
THE HEAD.
Engine RSV4 Factory a-PRC
ENG - 338
