CRANKSHAFT BUSHINGS - CONNECTING RODS
Three types of semi-bushing are available:
•
Blue
•
Red
•
Yellow
There are no dimension classes for the crank pins or the connecting rods. As a result, only the two
semi-bushing combinations are possible:
1. BLUE - BLUE (recommended solution)
2. YELLOW - RED (if combination 1 is not possible)
In combination 2, the YELLOW semi-bushing must be installed on the connecting rod shank and the
RED semi-bushing must be installed on the cap.
CRANKSHAFT BUSHING REPLACEMENT PROCEDURE
When replacing the big end bushings, make sure that the tang of the semi-bushing is correctly housed
in the corresponding notch in the connecting rod shank or cap
RSV4 Factory a-PRC Engine
ENG - 367
