Fix the sleeve in a vice, taking care not
to damage the sleeve.
•
Insert the stanchion (1) into the sleeve
(2).
•
Fit the two half-shells of the special tool
on the wheel holder stanchion (1), be-
hind the oil seal (5).
•
Grip the special tool and push the oil
seal (5) into its seat on the sleeve (2).
•
Remove the tool.
•
Fit the retainer ring (4) into its seat on
the sleeve (2).
•
Push the dust gaiter (3) into its seat on
the sleeve (2), ensuring that it is loca-
ted correctly.
•
Grip the stanchion and move it repeat-
edly and slowly in opposite directions.
CAUTION
THE STANCHION MUST SLIDE FREELY IN THE SLEEVE
WITHOUT RESISTANCE.
Suspensions RSV4 Factory a-PRC
SUSP - 414
