Removing the rear wheel
•
Place the vehicle on its rear service
stand.
•
Loosen and remove the nut on the
wheel axle.
•
Retrieve the thrust washer and the left
hand chain tensioner slider.
•
Tap the wheel axle slightly to extract
the head from its seat.
•
Make the wheel move forward and re-
lease the gearing chain from the
sprocket.
•
Remove the wheel spindle together
with the right hand chain tensioner
skid.
•
Remove the wheel by freeing the disc
from the brake calliper.
•
Holding the outer rim of the sprocket
with both hands, slide off the final
transmission unit by pulling it parallel to
the wheel axis.
OPERATE WITH CAUTION. IF THE FINAL TRANSMISSION
UNIT IS INSTALLED ON THE ANTI-VIBRATION BUFFER
HOLDER, DO NOT TURN OVER O ROTATE THE REAR
WHEEL SPROCKET SIDE HORIZONTALLY, OR THE FINAL
TRANSMISSION UNIT COULD SLIDE OUT AND FALL, AND
THE SPROCKET MAY GET DAMAGED.
CAUTION
Suspensions RSV4 Factory a-PRC
SUSP - 424
