Check the sprocket (7) toothing for proper conditions.
If there is excessive wear:
•
Replace the sprocket.
TO PREVENT EARLY WEAR OF NEW COMPONENTS, REPLACE THE SPROCKET, PINION AND
TRANSMISSION CHAIN AT THE SAME TIME.
REAR WHEEL BEARINGS
•
Remove the rear wheel.
•
Clean the two sides of the hub with a
cloth.
Working from the wheel right side:
•
Remove the right spacer (9).
•
Remove the sealing gasket (10).
•
Remove the circlip (11).
CAUTION
THE CIRCLIP (11) IS FITTED ONLY ON THE WHEEL RIGHT
SIDE.
The spacer end (12) is fitted with slots (A) for the extractor teeth to pass through.
•
Take out the right bearing (13) with the specific extractor.
Specific tooling
AP8140180 Extractor for bushings
•
Collect the inside spacer (12).
Working from the wheel left side:
•
Take out the left bearing (16) with the
specific extractor.
Specific tooling
AP8140180 Extractor for bushings
•
Clean the inside of the hub thoroughly.
CAUTION
WASH ALL THE PARTS WITH CLEAN DETERGENT.
RSV4 Factory a-PRC Suspensions
SUSP - 429
