Chain sliders
•
Place the vehicle on its OPTIONAL
rear service stand.
•
Check that the pad (1) is not worn or
damaged. Replace it with a new one if
it is.
•
Check the chain guide (2) for wear.
•
Unscrew and remove the two screws
from the left rider footpeg protection.
•
Remove the rear wheel.
•
Unscrew and remove the upper screw
fixing the chain slider and retrieve the
washer.
See also
Removing the
rear wheel
