Front brake pump
FRONT BRAKE PUMP
pos.
Description Type Quantity Torque Notes
1 Screw fastening front brake fluid res-
ervoir to bracket
M6 1 7 Nm (5.16 lbf ft) -
2 Screw fastening brake fluid reservoir
mounting bracket to handlebar
M6 1 7 Nm (5.16 lbf ft) -
3 Screw fastening brake pipe grommet
to the lower yoke
M5 1 8 Nm (5.9 lbf ft) -
4 Front brake pump U bolt clamp M6 2 10 Nm (7.37 lbf ft) -
5 Front brake lever pin fixing screw M6 1 10 Nm (7.37 lbf ft) -
Braking system RSV4 Factory a-PRC
BRAK SYS - 470
