Rear brake pump
REAR BRAKE PUMP
pos.
Description Type Quantity Torque Notes
1 Rear brake rod lock nut M6 1 12 Nm (8.85 lbf ft) -
2 Rear brake pump fixing screws M6 2 8 Nm (5.9 lbf ft) -
3 Rear brake lever fixing screw M8 1 25 Nm (18.44 lbf ft) -
RSV4 Factory a-PRC Braking system
BRAK SYS - 471
