1. Side stand sensor
2. Fuel pump
3. Instrument panel
4. Left hand switch
5. Right hand switch
6. Water Temperature Sensor
7. Cooling fans
8. Upper injectors
9. Air temperature sensor
10.Intake connectors
11.Lower injectors
12.Air pressure sensor
13.Exhaust valve
14.Lambda probe
15.Speed sensor
16.Headlamp
17.Rear turn indicators
18.Fall sensor
19.Horn
20.Voltage regulator
21.Battery
22.Auxiliary fuses
23.Control unit
24.Hand grip position sensor
25.Intake ducts connector control unit
26.Alternator
27.Coils
28.Timing sensor
29.Starter motor
30.Oil pressure sensor
31.Inertia sensor platform
32.Quick Shift
33.Front tone wheel sensor
34.a-PRC controls
A RELAY CANNOT BE IDENTIFIED BASED ON THE FOLLOWING INDICATIONS ONLY: THIS HAS
TO BE DONE ALSO IDENTIFYING THE COLOUR OF THE RELAY CABLES.
Electrical system RSV4 Factory a-PRC
ELE SYS - 98
