Input definition – type Current Loop Device
(INPUT/OUTPUT, 1, )
INPUT DEFINITION State :false
Input :1 Trig. :latched
Type :CL Dev. Mode :active 1
CL Adr :1 continuous
Input :1 Event unlogged
0. .9, ^V, <>, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Input/Output Menu Page 109
Place cursor at TYPE
Select Type: ACTION and press (Unlock memory!)
Select function
*See Common Facilities - All Input Types, Page 111 for description of Input, State and
Test
The inputs on a current loop device (FM800/FR800 Series) can be used for further
processing through I/O Logic. The inputs are numbered as per the Input Description in
the Serial Communication Format.
For the I/O to work, the common must be disabled in the CL Device Menu (see page 52).
To Next Page
