Output definition – type Supervised Device Output
(INPUT/OUTPUT, 2, )
OUTPUT DEFINITION State :false
Output :1 Trig. :latched
Type :Sup DevOutput Mode :normal
Addr. :1/1 :ICC continuous
unlogged
more ^V, <>, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Input/Output Menu Page 109
Select Type: SUP DEV OUTPUT and press
0..9 or Select loop/address of sounder unit and press
Press [More ] to view Screen 2 of the outputs.
The selected output number will switch the output of a field (loop) device of the
ICC-SND type. The device is defined by its loop/address as well as the output channel
number of the device. The device type is confirmed on the screen when the loop/address
is entered.
The selected device is operated by the logic that assigns the output true or false. In
addition the device is further controlled by:
Trigger: Latched/unlatched
Mode: Normal/inverted
Continuous/pulse/pulsing
Unlogged/Logged
Text: Allowed
* See Output Description in the Serial Communication Format
