Panel ID
(CONFIGURATION, 3, )
IDENTIFICATION
Change of Node ID Clears Eventbuffer!
Node : 1 / 0 Max. Config.:15/15
Panel : 1
0. . 9, ^V, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Configuration Menu Page 26
Select item to be changed
or 0..9 change data in item (Unlock memory!)
Confirm change
Return to Configuration Menu Page 26
For Panel ID Text Fields (2 lines x 40 characters):
Use to obtain the text line to be changed
Press (Unlock memory!)
Use to toggle between alpha and numeric text
Press the alpha/numeric button required
Use to move the cursor within the line
Press when completed
Default:
ID: 1/0
Panel: 1
Max. Config.: 15/15
Each FP2000 fire panel, as well as global repeaters, global zone repeaters and local
repeaters in a network system, can be uniquely identified by means of the panel ID. The
panel ID is used for the upload/download of data via the serial ports, as well as
information transfer on the network. In addition to the panel ID, two lines of user text can
be assigned to each fire panel or repeater. The user text is displayed on the System
Status Screen and for the logging of all system (general) fault warnings of the panel.
The Panel ID consists of two digits: fire panel number/repeater number (p/r).
For fire panels the repeater number is always Ø
e.g.: 0/0 - fire panel Ø
12/0 - fire panel 12
For global repeaters or global zone repeaters (network systems only) the fire panel
number is zero, and the repeater number defines the global repeater
e.g.: 0/1 - global repeater number 1
0/3 - global repeater number
For local repeaters attached to a particular fire panel on the network, the fire panel
number and the repeater number defines the repeater
e.g.: 1/3 - repeater 3 of fire panel 1
3/1 - repeater 1 of fire panel 3
