Test report [LCD]
(FULL TEST REPORT, LCD, )
FULL TEST REPORT 12/01/99 11:31
Zone :1 on :12/01 11:29 off :12/01 11:30
Addr Type Fire on Fire off
1/2 MCP flt flt
1/4 OPT flt flt
1/5 TEMP flt flt
0. .9, ^V, <>, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Zone Test Menu Page 176
Select zone/Addr.
Zone selected:
Enter 0..9, or use to select zone
Address selected:
Scroll screen up
Scroll screen down
The full test report is listed in order of zone and loop/address. The cursor will toggle
between zone and address. The screen can be scrolled when ‘Addr.’ is selected with the
cursor.
The screen will show the following:
• The zone number of the test report
• The date and time the test was started
• The date and time the test was finished
• A list of the testable devices
The devices that successfully entered into a fire condition are marked "OK" under the
"FIRE ON" column, otherwise they are marked as "FLT". When the device returns to
normal from the fire condition, it is flagged "OK" under the "FIRE OFF" column.
The LCD screen is not a dynamic display and shows the conditions at the time of
acquiring the report. To obtain an update of the screen, the user should exit and re-enter
this menu.
To Next Page
