Exception test report [LCD]
(EXCEPTION TEST REPORT, LCD, )
EXCEPTION TEST REPORT 12/01/99 11:31
Zone :1 on :00/00 00:00 off :00/00 00:00
Addr Type Fire on Fire off
1/2 MCP flt flt
1/4 OPT flt flt
1/5 TEMP flt flt
0. .9, ^V, <>, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
The exception test report is listed in order of zone and loop/address. The cursor will
toggle between zone and address. The screen can be scrolled when the ‘Addr.’ is
selected with the cursor.
The screen will show the following:
• The zone number of the test report
• The date and time the test was started
• The date and time the test was finished
• A list of the testable devices that have failed or had not been tested
The LCD screen is not a dynamic display and shows the conditions at the time of
accessing the screen. To obtain an update of the screen, the user should exit and re-
enter the menu.
