Aritech FP2000 Series Reference Guide

Common facilities – all output types
* See Output Description in the Serial Communication Format
Output: number
Enter number or use to view/change the existing defined
outputs, or create a new output. Each output required for the I/O
logic system must be defined by a unique output number. Unused
outputs have type None. The maximum number of outputs (default
100) may be set in Memory Allocation (Page 33).
Type: type
Output numbers are set true or false by logic. The action of the
output number is defined in the following types.
None no output defined (default)
General Page 131
Zone Page 132
Area Page 133
Internal Page 134
Device Output Page 135
Supervised Internal Page 136
Supervised Device Output Page 137
Network Page 138
Current Loop Device Page 139
Supervised Current Loop Device Page 140
Event Page 141
Action Page 142
Fct: function
The functions available depend on the output type selected. Refer
to the page of the specific function for further details.
State: true/false
This view field shows the state of the output. The output state is set
by logic and conditioned by the Trigger and Mode of the output
definition.
Trig: latched/unlatched
Latched
The output state, once switched true, will remain true until the fire
panel is reset even though the output conditions may become false
before the reset.
Mode: normal/inverted
• Normal
The output device is active when the output state is true.
• Inverted
The output device is active when the output state is false.
continuous/pulse/pulsing
