Indicating circuit controller
(DEVICE MENU, 1, , )*
SCREEN 2
DEVICE SETUP ClrStat
Address :1/10 Status :en State :NML
CommQlt :100% FldType :ICC FldDt :32 ARI
Mode :off
more 0. .9, ^V, <>, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Device Menu Page 78
Select field to be changed
Enter number 0..9 or to change data Confirm entry
Press [More ] to view Screen 1 of the device
The above screen is produced for sounder circuit controllers in order to view the device
status and statistics.
Only two parameters can be changed on this screen:
Address: Loop/address - Select a different device
ClrStat: Clear the statistics of this device.
*See Clear Device Statistics, Page 162 to clear all devices in a loop.
The parameters that can be viewed are:
Status: Enabled, Disabled or Soak: Shows if the device is currently
active or not. This can be changed on Screen 1 of the device (Page 79).
State: The latched alarm or fault state of the device. *See Screen 1
(Page 79).
CommQlt: Communication Quality: The number of correct replies from the
device as a percentage of the total number of polls to the
device. Communication quality is updated every 20 minutes
except when the device is being viewed, in which case it is
updated once per minute.
FldType: Field Type: The device type as seen by the fire panel. *See
Page 80 for field type descriptions.
FldDt: One of two values are returned:
16 - Fault
32 - Normal
The protocol being used to communicate to this device is also
displayed. They are: ARI - Aritech Series 2000
X90 - Aritech Series 900
X95 - Aritech Series 950
Mode: The current state of the sounder. The sounder can be in one of
three states:
