Output definition – type Current Loop Device
(INPUT/OUTPUT, 2, )
OUTPUT DEFINITION State :false
Output :1 Trig. :latched
Type :CL Dev. Mode :normal
CL Adr :1 continuous
Output :1 unlogged
more 0. .9, ^V, <>, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Input/Output Menu Page 109
Move to TYPE field
Select Type: NETWORK and press
Press [More ] to view Screen 2 of the outputs.
Rep.: The address of the fireman’s panel or other current loop device
Output: The output, at the current loop device, to be switched
Trigger: Latched/unlatched
Mode: Normal/inverted
Continuous/pulse/pulsing
Unlogged/logged
Text: Allowed
* See Output Description in the Serial Communication Format
The outputs are numbered as per the Output Description in the Serial Communication
Format
