Board information
(HARDWARE CONFIGURATION 2, or, , )
BOARD INFORMATION
Addr. :17 Sup1:passive Inp5:passive
ID :20 Sup2:passive Inp6:passive
Type :VDS Sup3:passive Inp7:passive
Sup4:passive Inp8:passive
X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Hardware Configuration 2 Page 31
This includes:
• Board description
• Actual board address
The board address is used in certain I/O programming
The board description and address in a two loop, 16 zone FP2000 is given below. Note
that board addresses are changed automatically when additional PC boards are added or
removed. When more than one loop driver or zone board is present in a system, then
each one of these boards assumes a unique address.
PC Board Description Address
DEN Common Display (EN Type) 0
ZON 16 Way Zone Board 1
PSH Host Power Supply 8
LPA 2 Loop Class A Driver 16
VDS Common Input/Output 18
FEP Front End Processor 24
HST Host CPU 25
KBD Keypad 26
LCD Liquid Crystal Display 27
PSF FEP Power Supply 28
