Output definition – type Supervised Internal
(INPUT/OUTPUT, 2, )
OUTPUT DEFINITION State :false
Output :1 Trig. :latched
Type :Sup Internal Mode :normal
Board :17:VDS continuous
Output :1 unlogged
more 0. .9, ^V, <>, E, X
Alarms: 0 Faults: 0 Cond.: 0 P: 1 SDZ
Return to Input/Output Menu Page 109
Select Type: SUP INTERNAL and press
0..9 or Select board address and press
0..9 or Select relay number and press
Press [More ] to view Screen 2 of the outputs.
The selected relay is operated by the logic that assigns the output true or false.
Trigger: Latched/unlatched
Mode: Normal/inverted
Continuous/pulse/pulsing
Unlogged/Logged
Text: Allowed
* See Output Description in the Serial Communication Format
