The parameters set by the user are:
• Address: loop/address - Select the device to be viewed.
• Status: enable/disable/soak - This determines if the device is currently
active or not. When a device is in "soak",
no alarm condition or outputs will be
triggered when the device comes into
alarm — it will only be reported as an
event.
• Zone: 1—112 - Devices are allocated to zones.
Zones may be in the displayable range of
the FP2000 as determined by the front
panel.
• Type: user type - The particular device type that the user
requires at the selected loop/address.
This is compared to the field type (Screen
2) which is the actual device type
responding to the fire panel at that
loop/address. A mismatch between the
Type and Field type will cause one of three
fault warnings:
Type Field Type Fault
any type None Communication fault
none any type Device disabled
any type different type Wrong type
The field type recognised by the fire panel is one of the following types. These types are
further expanded by the user to define the particular type. The particular user type defines
Screen 2, and in some cases the operation, for that device.
Type Field Type Description
1O
[1
I/O Single channel Output unit
1I/O
[1
I/O Single channel input single channel output unit
2I/O
[2
2I2O 2 channel input 2 channel output unit
2I1O
[1
I/O 2 channel input 1 channel output unit
3I/O
[1
I/O Three channel I/O unit
4I/O
[2
4I4O 4 channel input 4 channel output unit
4I
[2
4I 4 channel input unit
CUM
[1
MON Control monitor unit
GCU1
[1
I/O I/O section of gas unit
GCU2
[1
MCP Gas unit manual call point
ICC
[2
ICC Indicating circuit controller
ION ION Ionization smoke monitor
MCP MCP Manual call point
MCPM MCP Manual call point monitor
MCPW MCP Manual call point warning
MUL
[1
MUL Multi-Sensor (Optical/Heat detector)
OPT OPT Optical smoke monitor
SMI
[1
MCP Switch monitor unit with interrupt
SMU
[1
MON Switch monitor unit
SMU+
[1
MON Switch monitor unit plus
SIM
[2
SIM Single Input Module
SND
[1
SND Sounder circuit controller
TEMP TEMP Heat detector
ZMU
[1
MON Zone monitor unit
ZMU
[2
ZMU Zone monitor unit
The gas control unit occupies two consecutive addresses. The first (even) address is an
I/O unit and must be set to GCU1. The second (odd) address is a MCP and must be set
to GCU2.
