4.13.3 Controlling outputs
/LQH6XEOLQHV±$XWKRUL]DWLRQOHYHO&
Note!
For certain outputs to be activated, the door must be closed
and locked.
All digital outputs can be controlled. The sub-line number
corresponds to the number of the output, as follows (connection:
line 99, activation: line 97):
Output Function
01 Valve, cold water
02 Valve, hot water.
03 For future use
04 External cooling/Red LED/Fan
05 Pump, rinse-aid
06 Main pump
07 Steam Generators
08 Pump, descaler
09 Spray pump
10 Pump, process agent
12 Third element
16 Cooling fan CPU
19 Door opening
20 Door closing
00 = Output not active
01 = Output active
4.13.4 Read temperature
Line 83, sub-lines 1 - 2
83:1 Reading the current temperature sensor value.
0 - 150°C/32 - 302°F in 1° intervals.
This value cannot be changed.
83:2 Reading the current independent temperature sensor value.
0 - 150°C/32 - 302°F in 1° intervals.
This value cannot be changed.
