Arjo Tornado - Input Connections

57
4.16.3 Input connections
/LQH6XEOLQHV±$XWKRUL]DWLRQOHYHO)DFWRU\
This line number is used to tell the software which physical inputs
are connected to each logical input in the program.
Note!
Some sub-line numbers are not included. They are reserved
for future use.
The sub-line numbers correspond to the following logical inputs:
7KH³3K\VLFDOLQSXWV´FROXPQVKRZVWKHGHIDXOWFRQQHFWLRQ
Sub-line no. Function Physical
input
01 Conn., low level, tank 1
02 Conn. intermediate level tank 2
03 Conn., high level, tank 3
04 Conn., descaler, low level 5
05 Connection descaler empty 16
06 Connection chemical agent low
level
5
07 Connection chemical agent
empty
16
08 Connection rinse-aid low level 6
09 Connection rinse-aid empty 16
10 Conn., process agent, low level 7
11 Connection process agent
empty
16
12 Conn., spray agent, low level 8
13 Connection spray agent empty 16
14 Conn., leakage sensor, waste
outlet
4
15 Conn., door closed 11
17 Door open (FD1810) 12
20 Connection of safety switch,
door closing (FD1810)
13
21 Connection pedal (FD1810) 14
