4.13.2 Reading inputs
/LQH6XEOLQHV±$XWKRUL]DWLRQOHYHO&
All digital inputs can be read. The sub-line number corresponds to
the number of the input, as follows (connection: line 98, activation;
line 96):
Input Function
01 Low level, tank
02 Intermediate level, tank
03 High level, tank
04 Leakage sensor
05 Level, descaler/chemical agent
06 Rinse-aid
07 Level, process agent
08 Level spraying agent
11 Door closed
12 Door locked/Door open with automatic door
13 Crush protection, automatic door
14 Foot pedal
00 = Input not active
01 = Input active
