4.16.4 Connection outputs
/LQH6XEOLQHV±$XWKRUL]DWLRQOHYHO)DFWRU\
This line number is used to tell the software which physical outputs
are connected to each logical output in the program.
Note!
Some sub-line numbers are not included. They are reserved
for future use.
The sub-line numbers correspond to the following logical outputs:
7KH³3K\VLFDORXWSXW´FROXPQVKRZVWKHFRQQHFWLRQVVHWDWWKH
factory:
Sub-line no. Function Physical
input
01 Conn., pressure pump 6
02 Conn., steam generator 7
03 Conn., cold water 1
04 Conn., hot water 2
05 Conn., soft water 8
06 Connection PE system
(Rotating nozzle)
14
07 Connection SP system
(Spray nozzle)
13
08 Connection Extra nozzle 15
10 Connection pump, descaler 8
11 Connection pump chemical
agent
7
12 Connection pump rinse-aid 5
13 Connection pump, process
agent
10
14 Connection pump spray agent 9
15 Connection, extra element,
steam generator
12
16 Connection, condensate cooler 3
17 Connection, external cooling 4
23 Connection relay corresp. to
yellow LED
16
24 Connection relay corresp. to
red LED
15
26 Process active/Cooling fan
CPU
16
