4.4.3 Sub-line numbers
Each sub-line number corresponds to a button or a combination
of buttons. Choose programs and program names for the buttons,
based on the equipment of the machine.
The sub-line numbers are as follows:
Sub-line Function Comments
11
Program selection button .
Normally, 1 is programmed. Economy
program here.
12
Program name button
.
21
Program selection button .
Normally, 2 is programmed. Normal
program here.
22
Program name button .
31
The program selection buttons
and
are pressed at the same time.
Normally, 4 is programmed. Normal
program + process agent here.
32
Program name buttons
and are
pressed at the same time.
41
Program selection button .
Normally, 3 is programmed. Intensive
program here.
42
Program name button
.
51
The program selection buttons and
are pressed at the same time.
Normally, 5 is programmed. Intensive
program + process agent here.
52
Program name buttons
and are
pressed at the same time.
61
Program selection button .
1RUPDOO\LVSURJUDPPHG5LPÀXVKLQJ
here.
62
Program name button
.
71 Program selection for pedal FD1810
72 Program name for pedal FD1810
81 Program selection for pedal + button 5 FD1810
82 Program name for pedal + button 5 FD1810
91 Program selection IR FD1810
92 Program name IR FD1810
101 Program selection IR + button 5 FD1810
102 Program name IR + button 5 FD1810
150 IR function FD1810
0 = no IR, 1 = Open/close door,
2 = start program
