Arjo Tornado - Checking Fuses (1.1.1)

66
6.2.2 Checking fuses (1.1.1)
WARNING!
Only to be carried out by authorized staff.
WARNING!
The machine is connected to the electricity supply
and some components are live.
WARNING!
Show precaution, as some components are
sensitive to ESD.
The disinfector has the following four fuses:
• )P$77KLVIXVHLV¿WRQWKHGRRUFORVLQJERDUG
• )P$77KLVIXVHLV¿WRQWKHGRRUFORVLQJERDUG
• F01 - 500 mA T CPU - Relay board
• )±SROHGDXWRPDWLFIXVH&$ZKLFKSURWHFWVSDUWVRI
the high-voltage components of the machine
F01
F1, F3
F03
001439
Figure 4. Placement of fuses
