Arjo Tornado - Component Descriptions

93
8.3 Description
Note!
Some components are extra equipment.
-A01 Control system,
processor board
-M03 Motor, process pump
-A10 Control card lock motor -M04 Motor, descaler pump
-A11 Display keypad -M06 Ventilator fan
-B01 Level sensor, tank -M07 Motor, rinse-aid pump
-B02 Level sensor, descaling -M16 Locking motor
-B04 Level sensor, process -M17 Cooling fan
-B05 Leakage sensor* (one is
optional)
-M18 Motor, door
-B06 Level sensor, rinse-aid -S03 Limit switch, door
closed
-B07 Temperature sensor
PT-1000 (two sensors in
one sensor body)
-S04 Switch door closed (fan)
-S05 Limit switch, door
locked
-E01 Electric element in
steam generator
-S11 Foot pedal
-F01 Fuse on PCBA board
500mAT
-T02 Transformer 1-phase
-F1 Fuse locking door board
400mAT
-T03 Transformer 3-phase
-F3 Fuse door lock board
200mAT
-T04 Transformer 3-phase
415VAC
-F03 Fuse 2-poled C13 -U01 Power supply 24VDC
-K02 Contactor, electric
element in steam
generator
-Y01 Solenoid valve, cold
water
-K03 Relay ventilator fan -Y02 Solenoid valve, hot
water
-K04 Automatic door: -X50 Terminal strip
-M01 Motor, main pump -Q01 Power cut-off device
