Automatic Divider-rounder model Syncro
19/79
Use and maintenance manual (translation of the original instructions) - MASA6_en_2 of 23/03/2021
To remove the machine from the support pallet, after having inserted the forklift arms (forks) in the appropriate
slots (making sure that they protrude from the rear side of the machine by at least 200 mm), lift the machine by
about 150 mm, then move the machine and place it slowly on the supporting floor. See also Figure 9.
Figure 9 - Lifting and handling the machine with a forklift truck
Forklift arm insertion points; they must
protrude by at least 200 mm from the
opposite side
Figure 8 - Fixing the machine to the pallet
