ARTEZEN SYNCRO - 3.11 Emptying the Machine; Figure 32 - Emptying

Automatic Divider-rounder model Syncro
44/79
Use and maintenance manual (translation of the original instructions) - MASA6_en_2 of 23/03/2021
3.11 EMPTYING THE MACHINE
Emptying is necessary in the following cases:
 If the work program needs changing;
 If the need arises to remove any dough still present in the
machine at the end of the working day.
Emptying must be carried out at the end of the temporary stop of
processing, as illustrated in par. 3.9: the display will show the top
in Figure 32; press ESC par 2.4ref. 7 to start the emptying cycle at the
end of which the display will show the list of selectable recipes, as at
the start of the work phase.
During the entire emptying phase, the display will show a screen that
simulates the emptying of the machine (see the centre image in Figure
32 ).
Figure 32 - Emptying
