ARTEZEN SYNCRO - Table 11- Coded Alarm List and Possible Solution

Automatic Divider-rounder model Syncro
62/79
Use and maintenance manual (translation of the original instructions) - MASA6_en_2 of 23/03/2021
ALARMS
INSTRUCTIONS
DEVICE
DESCRIPTION
01
KMG
Main power line contactor faulty
IO0501
02
GF2
Alarm for drum inverter
IO0502
03
GF3
Alarm for moulding plate frequency
converter
IO0503
04
QTx
Circuit breakers triggered
IO0504
05
S1
Rounding cam sensor faulty or broken
IO0505
06
S8.1
Zero position weight cam position sensor
faulty or broken
IO0506
07
S3
Large pocket sensor faulty or broken
IO0507
08
S4
Small pocket sensor faulty or broken
IO0508
09
S5
Star dosing device sensor faulty or broken
IO0509
10
S6
Dough feeding sensor faulty or broken
IO0510
11
GF1
A1
CANopen lack of connection
IO0511
12
GF1
Alarm for brush-less drive
IO0512
13
A1
A2
Lack of connection between monitor and
main control board
IO0513
14
S7.1
Zero position drum sensor faulty or broken
IO0514
15
S7
Drum position sensor faulty or broken
IO0515
16
S8
Weight cam position sensor faulty or
broken
IO0516
17
Incorrect recipe parameters
IO0517
18
ET1
Safety control unit faulty
IO0518
19
Y1
Compression piston solenoid valve faulty
IO0519
20
KV1
Star dosing device contactor faulty
IO0520
21
KV2
Drum flour duster contactor faulty
IO0521
22
KV3
Belt moving contactor faulty
IO0522
23
KM4
Oil-hydraulic pump contactor faulty
IO0523
24
KM5.1
Weight increase cam contactor faulty
IO0524
25
KM5.2
Weight decrease cam contactor faulty
IO0525
26
KM7
Loaf moulder station lower belt contactor
faulty
IO0526
27
KM8.1
Loaf moulder station 1
st
speed upper belt
contactor faulty
IO0527
28
KM8.2
Loaf moulder station 2nd speed belt
contactor faulty
IO0528
29
Drum mechanic block
IO0529
30
Weight cam mechanic block
IO0530
Table 11- Coded alarm list and possible solution
