Automatic Divider-rounder model Syncro
20/79
Use and maintenance manual (translation of the original instructions) - MASA6_en_2 of 23/03/2021
3.3 ELECTRICAL CONNECTION
Any electrical operation concerning the machine and / or the work site must be carried out by specialized and
expert technicians, familiar with the technical and regulatory notions to perform the work in a workmanlike
manner and in safe conditions, according to the laws in force; they must issue any declaration of conformity
required by the law.
Upon delivery of the machine, and in any case before proceeding with the electrical connection, make sure that
the line voltage corresponds to the one declared by the manufacturer on the plate (par. 2.5) and on the
wiring diagram.
The machine is supplied with an electric cable with a 5-pole 16 A plug (L1 + L2 + L3 + N + PE).
The site's electrical system must have suitable characteristics for maximum load absorption For the connection,
the user must provide a socket in compliance with the laws and regulations in force and powered with
conductors of adequate cross-section on the basis of the data given in this manual and in the wiring diagram.
Use the appropriate earthing system, whose efficiency must be periodically checked; do not connect to gas or
water pipes or other generic metal parts. Keep the power cord away from hot and / or moving parts; it must not
obstruct the passage of people, animals, things. The plug must be easily accessible and clearly visible from any
position in which the operator may be, even for a short time.
3.4 PRELIMINARY CHECK
Some machine parts must be removed to be cleaned and must be put back in place once the sanitizing
operations have been completed. With reference to Figure 10,
Open the front doors;
Remove the front cover of the head (Pos. 1) by sliding the bridge handle in the direction of the arrow;
Open the bottom door (Pos. 2) by turning the locking lever in the direction indicated by the arrow and tilt
the door downward;
Check the presence and correct installation of:
o The brush (Pos. 3);
o The two star dosing devices (Pos. 4);
o The 6 dough accompanying rollers (Pos. 5);
o The dough compression piston and relative locking pin (pos. 6);
o Removable dough removing roller unit (in this case, failure to install the roller unit would
generate an alarm situation and the inability to start processing; the display would show the
image here below). In any case, check that the unit is correctly fitted in its seat in a stable
manner and locked in position by means of the locking lever.
ATTENTION
Never use lifting systems and/or devices other than those illustrated in this manual.
When handling and/or transporting the machine, take every possible precaution in order to prevent,
or reduce as much as possible, the occurrence of risks to persons, animals, or property.
