Automatic Divider-rounder model Syncro
79/79
Use and maintenance manual (translation of the original instructions) - MASA6_en_2 of 23/03/2021
5.4 SAFETY SIGNS
The following safety signs are affixed onto the machine.
Danger of electrocution (shock)
on the outside of each enclosure with electrical parts at > 24 V
ATTENTION! Danger of gripping, dragging, crushing of hand;
on the interlocked door of the weight chamber, on the fixed side guards, on the panel
screwed to the top section of the outfeed belt guard
ATTENTION! Hand shearing hazard
on the outside of the hopper on two opposite sides of the hopper
ATTENTION! Moving parts. Danger of gripping, dragging, crushing, abrasion;
on the fixed side guards, on the panel screwed to the top part of the outfeed belt guard
It is prohibited to remove the guards and/or disable the safety devices;
on the interlocked door of the weight chamber, on the fixed side guards, on the panel
screwed to the top section of the outfeed belt guard
It is prohibited to clean, lubricate, etc. the components of the machine while they are
moving;
on the interlocked door of the weight chamber, on the fixed side guards, on the panel
screwed to the top section of the outfeed belt guard
Check that the images and colours of the signs are in perfect condition; as soon as any sign of
deterioration is found, replace them immediately.
6 DISMANTLING
Should the owner decide to proceed with the dismantling of the machine, the various components must be
separated by type of material and disposed of in conformity with the laws and regulations in force; indications
concerning materials that constitute the most relevant parts of the machine are given below.
Stainless steel: load bearing structure and electrical box (if requested by the client); fixed guards screwed on
and with key; hopper; external casing of the weight chamber; load bearing structure for the output
belt; dividing head.
Painted steel: load bearing frame and electrical box (if requested by the customer)
Teflon-coated stainless steel: hopper (optional), double belt divider
Plastic, rubber: belts; divider and dividing unit piston; dough ejection blocks; flexible hoses
Miscellaneous materials: motors (copper windings); electrical, electronic, and oil-hydraulic components
Drain the oil from the oil-hydraulic unit tank; used oil must be disposed of in compliance with the environmental
protection laws in force.
For the disposal of the different materials, it is best to contact companies specialised in waste disposal that
must provide their services in conformity with the current laws.
