Automatic Divider-rounder model Syncro
64/79
Use and maintenance manual (translation of the original instructions) - MASA6_en_2 of 23/03/2021
o Check the connection present in board “A1” to wire
number “703” of terminal board “M7”;
o Board “A1” may be faulty;
Proximity sensor “S4” not
reading– Small rounding
cup
o Sensor “S4” broken - replace it;
o Sensor "S4" disconnected from the connector - unscrew
and re-tighten the connecting ring nut;
o Sensor "S4" unscrewed from its seat - Screw it back up
to a distance of 0.5 ÷ 1 mm from the reading references;
o In manual work mode (par. 6.2.7), select page “H” and
press “START” for 10 seconds: the cup conveyor (Figure 1 ref. 6)
must be moving; if not, the “M3” motor is blocked - check for any
obstruction to the movement;
o Check the connection present in board “A1” to wire
number “704” of terminal board “M7”;
o Board “A1” may be faulty;
o Proximity sensor
“S5” not reading– Star
dosing devices stopped;
o "KV1" not
working - probable
breakage.
o Sensor “S5” broken - replace it;
o Sensor "S5" disconnected from the connector - unscrew
and re-tighten the connecting ring nut;
o Sensor "S5" unscrewed from its seat - Screw it back up
to a distance of 0.5 ÷ 1 mm from one of the 3 vertexes of the
stopping cam near sensor “S5”;
o In manual work mode (par. 4.11) select page “B” and
press “START” for 10 seconds: the two star dosing devices
installed inside the head (Figure 37 Pos. must be moving: if this
is not the case, the “M1” motor is blocked - check for any
obstruction to the movement;
o Check the connection present in board “A1” to wire
number “705” of terminal board “M7”;
o Board “A1” may be faulty;
o Check that the cam placed near “S5” is well fixed on the
rotation axis, and if necessary lock it in position. During the work
cycle, the star dosing units must stop with the lower vertex
vertical with respect to its own work axis;
o Replace “KV1”.
Proximity sensor “S6” not
reading– The dough
compression piston has
reached the end of its
travel
o Sensor “S6” broken - replace it;
o Sensor "S6" disconnected from the connector - unscrew
and re-tighten the connecting ring nut;
o Sensor "S" unscrewed from its seat - Screw it back up to
a distance of 0.1 ÷ 0.3 mm from the internal profile of the dough
compression chamber.
o Failed insertion of dough compression piston (Figure 37
Pos. 6) in its working seat - Check the presence of the piston;
check that the metal pin connecting the piston is inserted all the
way in its seat; check that the plastic piston can slide along its
entire travel distance, up to the cylindrical dividing drum placed
on the left end;
o Hydraulic piston drive unit off or unable to function; no oil
in the tank; clogged oil suction filter.
o Check the connection present in board “A1” to wire
number “706” of terminal board “M7”;
o Board “A1” may be faulty;
No CANopen connection
between "GF1" and "A1"
o Possible incorrect earthing of the machine - check the
earthing of the power supply system;
o Check the connection to the terminal block "M11" in
board A1, and to “U1” in "GF1";
o Board “A1” may be faulty;
o “GF1” may be faulty;
o Remove the earthing filter installed next to "GF1" visible
thanks to a metal screw with the symbol next to it
o Check the fuses in “F4” and replace them if necessary
Turn off the machine, open the rear electrical box, then restart the
