TM 9-4935-601-14-7&P
TABLES
Table Page
1-1 Specifications ................................................................................ 1-8
1-2 Recommended Test Equipment .................................................... 1-13
1-3 Recommended Test Accessories .................................................. 1-20
4-1 Performance Test Record ............................................................. 4-77
4-2 Recommended Test Abridgements ............................................... 4-85
5-1 Factory Selected Components ...................................................... 5-2
5-2 Post-Repair Test and Adjustments ................................................ 5-4
5-3 RF Filter Check ............................................................................. 5-26
6-1 Part Numbers for Exchange Assemblies ....................................... 6-2
6-2 Reference Designations and Abbreviations ................................... 6-3
6-3 Replaceable Parts ......................................................................... 6-5
6-4 Code List of Manufacturers ........................................................... 6-42
7-1 Manual Changes by Serial Number ............................................... 7-1
7-2 Summary of Changes by Component ............................................ 7-2
8-1 Etched Circuit Soldering Equipment .............................................. 8-4
8-2 Logic Levels .................................................................................. 8-6
8-3 Assembly Information Index .......................................................... 8-14
8-4 Schematic Diagram Notes ............................................................. 8-15
8-5 Meter Drive Amplifier Data ............................................................ 8-52
8-6 Total Count of Time Base Reference Counters U13,
U14, and U15 ........................................................................... 8-56
8-7 Count Modes of Counters A8A3U13 and U14 ................................ 8-56
8-8 Count Modes of Counter A8A3U15 ................................................ 8-56
8-9 Data Inputs of Decimal Point Shift Register ................................... 8-56
ILLUSTRATIONS
Figure Page
1-1 HP Model 8640B Signal Generator (Option 001) and
Accessories Supplied ................................................................ 1-0
1-2 Measured Single Sideband Noise vs Offset from Carrier................ 1-2
1-3 Specified Signal-to-Phase Noise Ratio .......................................... 1-3
1-4 AM Distortion vs AM Rate ............................................................. 1-4
1-5 Pulsed RF ..................................................................................... 1-4
1-6 FM Distortion vs FM Rate .............................................................. 1-5
1-7 520 MHz Notch Filter .................................................................... 1-21
1-8 FM Linearity Circuit ....................................................................... 1-22
2-1 Line Selector ................................................................................. 2-1
2-2 Power Cables Available ................................................................ 2-2
2-3 Preparation for Rack Mounting ...................................................... 2-4
