artisan 8640B - Counter External Sensitivity Test; FM 3 Db Bandwidth Test; FM Distortion Test; FM Sensitivity and Accuracy Test

Model 8640B TM 9-4935-601-14-7&P
Table 4-1. Performance Test Record (7 of 8)
Results
Para Test Description
No. Min Actual Max
4-38. FM 3 dB Bandwidth Test 3 dB
4-39. FM Distortion Test
Maximum Deviation 30.5 dB
1/8 Maximum Deviation 40 dB
4-40. FM Sensitivity and Accuracy Test
Sensitivity: Frequency Range
256-512 MHz 1.954 kHz 2.204 kHz
128-256 MHz 1.954 kHz 2.204 kHz
64-128 MHz 1.954 kHz 2.204 kHz
32-64 MHz 1.954 kHz 2.204 kHz
16-32 MHz 1.954 kHz 2.204 kHz
8-16 MHz 1.954 kHz 2.204 kHz
4-8 MHz 1.954 kHz 2.204 kHz
2-4 MHz 1.954 kHz 2.204 kHz
1-2 MHz 1.954 kHz 2.204 kHz
0.5-1 MHz 1.954 kHz 2.204 kHz
Accuracy: Frequency Range
256-512 MHz 1.871 kHz 2.287 kHz
128-256 MHz 1.871 kHz 2.287 kHz
64-128 MHz 1.871 kHz 2.287 kHz
32-64 MHz 1.871 kHz 2.287 kHz
16-32 MHz 1.871 kHz 2.287 kHz
8-16 MHz 1.871 kHz 2.287 kHz
4-8 MHz 1.871 kHz 2.287 kHz
2-4 MHz 1.871 kHz 2.287 kHz
1-2 MHz 1.871 kHz 2.287 kHz
0.5-1 MHz 1.871 kHz 2.287 kHz
4-41. Incidental AM Test
Maximum Deviation 1%
1/8 Maximum Deviation 0.5%
4-42. Counter External Sensitivity Test
0.5 to 550 MHz
(√)
20 Hz to 500 kHz
(√)
20 Hz to 10 MHz
(√)
4-43. Internal Reference Accuracy Test
15°C to 35°C 4,999,995 Hz 5,000,005 Hz
0°C to 55°C 4,999,985 Hz 5,000,015 Hz
