Model 8640 TM 9-4935-601-14-7&P
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A26A3CR5 NSR, PART OF A26A3CR1.
A26A3CR6 NSR. PART OF A26A3CR1.
A26A3CR7 NSR. PART OF A26A3CR1.
A26A3CR8 NSR. PART OF A26A3CR1.
A26A3J1 1250-1425 1 CONNECTOR-RF SMC MSGL HOLE RR 2K497 700177-1
A26A3J2 1251-2194 CONNECTOR-SGL CONT SKT .021-DIA 00779 3-331272 0
A26A3L1 9100-1620 COIL-FXD FOLDED RF CHOKE 15UH 10% 24226 15/152
A26A312 9140-0112 1 COIL-FXD MOLDED RF CHOKE 4.7UH 10% 24226 15/471
A26A3R1 0698-7229 1 RESISTOR 511 2% .05W F TC-0+-100 24546 C3-1/8-TO-511R-G
A26A3R2 0698-3132 RESISTOR 261 1% .125W F TC=0+-100 16299 C4-1/8-TO-2610-F
A26A3R3 0698-3132 RESISTOR 261 1% 125M F TC=0+-100 16299 C4-1/8-TO-2610-F
A26A3R4 0757-0416 RESISTOR 511 1%.125W F TC-0+-100 24546 C4-1/8-TO-511R-F
A26A3R5 0757-0416 RESISTOR 511 1.125W F TC=0+-100 24546 C4-1/8-TO-511R-F
A26A3T1 08640 80003 2 BALUN ASSY 28480 08640-80003
1251-2194 9 CONNECTOR-SGL CONT SKT .021-DIA 00779 3-331272-0
A26A3T2 08640-80003 BALUN ASSY 28480 08640-80003
1251-2194 CONNECTOR-SGL CONT SKT .021-DIA 00779 3-331272-0
A26A3XA26U2A-E 1251-2613 CONNECTOR-SGL CONT SKT .033-0lA 00779 50864-3
A26A4 08640-60015 1 AGC AMPLIFIER ASSY 28480 08640-60015
A26A4C1 0180-0291 CAPACITOR-FXC 1UF+-10% 35VDC TA 56289 150D105X9035A2
A26A4C2 0180-0291 CAPACITOR-FXD 1UF+-10% 35VDC TA 56289 150D105X9035A2
A26A4C3 0180-0291 CAPACITOR-FXC 1UF+-10% 35VDC TA 56289 150D105X9035A2
A26A4C4 0160-2307 2 CAPACITOR-FXD 47PF +-5% 300WVDC MICA 28480 0160-2307
A26A4C5 0160-2307 CAPACITOR-FXO 47PF +-5% 300WVDC MICA 28480 0160-2307
A26A4C6 0160-3458 1 CAPACITOR-FXD 5000PF +-10% 250WVDC CER 28480 0160-3458
A26A4C7 0180-0291 CAPACITOR-FXD IUF4+-=OX 35VDC TA 56289 150D105X9035A2
A26A4C8 0180-0197 CAPACITOR-FXD 2.2UF-=10% 200WVDC TA 56289 1500225X9020A2
A26A4C9 0160-0161 CAPACITOR-FXD .01UF +-10%: 200WVDC POLYE 56289 292P10392
4A6A4C10† 0160-0302 1 CAPACITOR-FXD .018UF +-10% 200WVDC POLYE 56289 292P18392
A26A4C11 0160-0159 1 CAPACITOR-FXO 6800PF +10% 200VDC POLYE 56289 292P68292
A26A4C12 0140-0191 1 CAPACITOR-FXD 56PF +-5: 300WVDC MICA 72136 DM15E560J0300WV1CR
A26A4C13 0180-0291 CAPACITOR-FXD 1UF+-10% 35VDC TA 56289 1500D105X9035A2
A26A4C14† 0160-0576 1 CAPACITOR-FXD .1UF 4=20 SO 5VDC CER 26654 2130BR050R104M
A26A4C15 0160-0297 1 CAPACITOR-FXD 1200PF +-10% 200WVDC POLYE 56289 292P12292
A26A4C16 0160-3534 CAPACITOR-FXD 510PF +-5% 100WVDC MICA 28480 0160-3534
A26A4C17 0160-3459 1 CAPACITOR-FXD .02UF +-20% 100WVDC CER 28480 0160-3459
A26A4CR1 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A26A4CR2 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A26A4CR3 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A26A4CR4 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO-35 28480 1901-0040
A26A4CR5 1901-0022 DIODE-STABISTOR 10V 250MA 28480 1901-0022
A26A4CR6 1901-0022 DIODE-STABISTOR 10V 250MA 28480 1901-0022
A26A4CR7 1910-0016 DIODE-GE 60V 60NA 1US DO-7 28480 1910-0016
A26A4CRB 1910-0016 DIODE-GE 60V 60NA 1US DO-7 28480 1910-0016
A26A4CR9 1910-0016 DIODE-GE 60V 60NA 1US DO-7 28480 1910-0016
A26A4CR10 1901-0022 DIODE-STABISTOR 1OV 250MA 28480 1901-0022
A26A4CR11 1901-0040 DIODE-SWITCHING 30V 50MA 2NS DO35 28480 1901-0040
A26A4CR12 1901-0022 OIODE-STABISTOR 10V 250MA 28480 1901-0022
A26A4CR13 1901-0539 DIODE-SCHOTTKY 28480 1901-0539
A26A4CR14 1901-0518 1 DIODE-SCHOTTKY 28480 1901-0518
A26A4CR15 1901-0040 DIODE-SWITCHING 30V SOMA 2NS DO-35 28480 1901-0040
A26A4K1 0490-1080 RELAY-REED IC .25A 150V CONT 5VCOIL 28480 0490-1080
A26A4L1 9100-1641 COIL-FXD MOLDED RF CHOKE 240UH 5% 24226 15/243
A26A4L2 9100-1641 COIL-FXO MOLDED RF CHOKE 240UH 5% 24226 15/243
A26A4MP1 4040-0749 EXTRACTOR-PC BD BRN POLYC .062-BD-THKNS 28480 4040=0749
1480-0073 PIN:DRIVE 0.250” LG 00000 OBD
A26A4NP2 4040-0753 EXTRACTOR-PC BD GRN POLYC .062-BD-THKNS 28480 4040-0753
1480-0073 PIN:DRIVE 0.250” LG 00000 OBD
A26A4Q1 1854-0221 TRANSISTOR-DUAL NPN PO=75OMW 28480 1854-0221
A26A4Q2 1854-0071 TRANSISTOR NPN SI PD=300MW FT=20OMH2 28480 1854-0071
A26A4Q3 1853-0007 TRANSISTOR PKP 2N3251 SI TO718 PO=360MW 04713 2N3251
A26A4Q4 1854-0221 TRANSISTOR-DUAL NPN PD=75OMW 28480 1854-0221
A26A4Q5 1853-0034 TRANSISTOR PNP SI TO-18 POD360MW 28480 1853-0034
A26A4Q6 1854-0071 TRANSISTOR NPN SI PO-300MW FT=200MHZ 28480 1854-0071
A26A4Q7 1853-0034 TRANSISTOR PNP SI TD-18 PD=360MW 28480 1853-0034
A26A4Q8 1854-0071 TRANSISTOR NPN SI PD0300MW FT=200MHZ 28480 1854-0071
A26A4Q9 1854-0071 TRANSISTOR NPN SI PO=300MW FT=200MHZ 28480 1854-0071
A26A4R1 2100-2521 2 RESISTOR-TRMR 2K 10% C SIDE-ADJ 1-TURN 30983 ET50X202
A26A4R2 2100-2521 RESISTOR-TRMR 2K 10% C SIDE-ADJ 1 TURN 30983 ET50X202
A26A4R3 0757-0401 RESISTOR 100 1T .125W F TC=0+-100 24546 C4-1/8-TO-101-F
A26A4R4 0757-0290 RESISTOR 6.19K 1% .125W F TC=0+-100 19701 MF4C1/8-TO-6191-F
A26A4R5 0757-0280 RESISTOR 1K 1% .125W F TC0+-100 24546 C4-1/8-TO-1001-F
See introduction to this section for ordering information.
6-36
