Model 8640B TM 9-4935-601-14-7&P
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A26A4R6 0757-0440 RESISTOR 7.5K 1% .125W F TC=0+-100 24546 C4-1/8-TO-7501-F
A26A4R7 0691-3154 RESISTOR 4.22K 1% 125W F TC=0+-100 16299 C4-1/8 TO-4221-F
A26A4R8 0757-0440 RESISTOR 7.5K 1% .125M F TC=0+-100 24546 C4-1/8-TO-7501-F
A26A4R9 0757-0465 RESISTOR 100K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1003-F
A26A4R10 0757-0442 RESISTOR 10K 1%.125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A26A4R11 0757-0042 RESISTOR 10K 1% .125W F TC=0+ 100 24546 C4-1/8-TO-1002-F
A26A4R12 2100-2514 1 RESISTOR-TRMR 20K 10% C SIDE-ACJ 1-TURN 30983 ET50W203
A26A4R13† 0698-3156 2 RESISTOR 14.7K 1% 125W F TC=0+-100 16299 C4-1/8-TO-1472-F
A26A4R14 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A26A4R15† 0698-3156 RESISTOR 14.7K 1% 125W F TC=0+-100 16299 C4-1/8-TO-1472-F
A26A4R16 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A26A4R17 0698-3453 1 RESISTOR 196K 1%.125 F TC=0+-100 16299 C4-1/8-TO-1963-F
A26A4R18 0698-3153 2 RESISTOR 3.83K 1% 125W F TC=0+-100 16299 C4-1/8-TO-3831-F
A26A4R19 0757-0464 1 RESISTOR 90.9K 1% .125W F TC=0+-100 24546 C4-1/8-TO-9092-F
A26A4R20 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A26A4R21 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A26A4R22† 0757-0278 RESISTOR 1.78K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1781-F
A26A4R23 0757-0290 RESISTOR 6.19K 1% .125W F TC=0+-I00 19701 MF4C1/8-TO-6191=F
A26A4R24 0698-0083 RESISTOR 1.96K 1% .125W F TC=0+-100 16299 C4-1/8-TO-1961-F
A26A42R5 0757-0458 2 RESISTOR 51.1K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5112-F
A26A4R26 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A26A4R27 0757-0458 RESISTOR 51.1K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5112-F
A26A4R28 0757-043S RESISTOR 5.11K 1% .125W F TC=0+-I00 24546 C4-1/8-TO-5111-F
A26A4R29 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A26A4R30 0757-0441 RESISTOR 8.25K 1% .125W F TC=0+-100 24546 C4-1/8-TO-8251-F
A26ASR31 0757-0317 RESISTOR 1.33K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1331-F
A26A4R32 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A26A4R33 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A26A4R34 0757-0465 RESISTOR 100k1% .125W F TC=0+-100 24546 C4-1/8-TO-1003-F
A26A4R35 0757-0465 RESISTOR 100K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1003--F
A46A4R36 0698 0083 RESISTOR 1.96K 1% .125W F TC=0+-100 16299 C4-1/8-TO-1961-F
A26A4R37 0757-0394 RESISTOR 51.1 15 .125W F TC=0+-100 24546 C4-1/8-TO-51R1-F
A26A4R38 0691-3153 RESISTOR 3.83K 1% .125W F TC=0+-100 16299 C4-1/8-TO-3831-F
A26A4R39 0757-0280 RESISTOR 1K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1001-F
A26A4R40 0698-3437 1 RESISTOR 133 1% .125W F TC =0+-100 16299 C4-1/8-TO-133R-F
A26A4R41† 0757-0465 6 RESISTOR 100K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1003-F
A26A4R42† 0757-0465 RESISTOR 100K 1% .125WF TC=0-=100 24546 C4-1/8-TO-1003-F
A26A4R43 0698-0083 RESISTOR 1.96K 1% .125W F TC=0+-100 16299 C4-1/8-TO-1961-F
A26ARR44 0698-3450 RESISTOR 42.2K 1% .125W F TC=0+-100 16299 C4-1/8-TO-4222-F
A26A4R45 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A26A4R46 0698-3154 RESISTOR 4.22K 1% .125W F TC=0+-100 16299 C4-1/8-TO-4221-F
A26A4R47 0757-0401 RESISTOR 10K 1% 125W F TC=0+-100 24546 C4-1/8-TO-1001-F
A26A4R48 0757-0289 RESISTOR 13.3K 1% .125W F TC=0+-100 19701 MF4C1/8-TO-1332-F
A26A4R49 0698-3150 RESISTOR 2.37K 1% .125W F TC=0+-100 16299 C4-1/8-TO-2371-F
A26A4R50 0698-3451 1 RESISTOR 133K 1% .125W F TC=0+-100 16299 C4-1/8-TO-1333-F
A26A4R51 NOT ASSIGNED
A26A4RS2 0757-0280 RESISTOR 1K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1001-F
A26A4R53 0757-0278 RESISTOR 1.78K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1781=F
A26A4R54† 0757-0421 3 RESISTOR 825 1% .125W F TC7=0+-100 24546 C4-1/8-TO-7825R-F
A26A451 3101-0973 1 SWITCH-SL DPDT-NS MINTR .5A 125VAC/DC PC 79727 GF126=0018
A26A4TP1 0360-1514 TERMINAL-STUO SGL-PIN PRESS-MTG 28480 0360-1514
A26A4TP2 0360-1514 TERMINAL-STUC SGL-PIN PRESS-MTG 28480 0360-1514
A26A4TP3 0360-1514 TERMINAL-STUO SGL-PIN PRESS-MTG 28480 0360-1514
A26A4TP4 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A26A4TP5 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A26A4TP6 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A26A4TP7 0360-1514 TERMINAL-STUC SGL-PIN PRESS-MTG 28480 0360-1514
A26A4TP8 0360-1514 TERMINAL-STUD SGL-FIN PRESS-MTG 28480 0360-1514
A26A4U1 1826-0092 1 IC MC 1458 DP AMP 28480 1826-0092
A26A4U2 1826-0026 1 IC LM 311 CCMPARATOR 27014 LM311H
A26A4U3 1820-0328 1 IC SN74 02 N GATE 01295 SN7402M
A26A4U4 1820-0471 1 IC SN74 06 N INV 01295 SN7406N
A26A4VR1 1902-0025 DIODE-ZNR 10V 5% DD-7 PD=.4W TC=+-.06% 04713 SZ 10939-182
A26A4VR2 1902-3203 1 DIODE-ZNR 14.7V 5% DD-7 PO-.4W TC=+-.057% 04713 SZ 10939-230
A26A5 08640-60009 1 RISER ASSY 28480 08640=60009
A26A5XA26A6 1251-3231 1 CDNNECTOR; PC EDGE; 15-CONT; WIRE WRAP 28480 1251-3231
A26A6 08640-60011 1 AM MOTHER BOARD ASSY 28480 08640-60011
A26A6XA2662 1251-1886 1 - CONNECTOR-PC EDGE 15-CONT/ROW 2-ROWS 71785 252-15-30-340
See introduction to this section for ordering information.
† SEE TABLES 7-1 AND 7-2, FOR BACKDATING.
6-37
