Model 8640B TM 9-4935-601-14-7&P
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
J1MP1 1250-0914 1 CONNECTGR-RF AP-CN FEM UNMTD 90949 131-150
J1MP2 1250-0915 1 CONTACT, RF CONNECTOR. FEF,ALE CENTER 71785 131-149
J1MP3 2190-0104 1 WASHER-LK INTL T NG.-7/16 .439-N-110 78189 1922-04
J1MP4 2950 0132 1 NUT-HEX-DBL-CHAM 7/16-28-THO .094-THK 73734 76500NP
J1MP5 5040-0306 1 INSULATOR 28480 5040-0306
J1MP6 08555-20093 2 CENTER CONDUCTOR 28480 08555-20093
J1MP7 08555 20094 1 BCDY, BULKHEAD 28480 08555-20094
J1MP8 08761-2027 1 INSULATOR 28480 08761-2027
Figure 6-2. Type N Connector
See introduction to this section for ordering information
6-41
