artisan 8640B - Performance Test Record

Model 8640B TM 9-4935-601-14-7&P
Table 4-1. Performance Test Record (1 of 8)
Hewlett-Packard
Model 8640B Tested By__________________________
Signal Generator
Serial No.____________________ Date______________________________
Results
Para Test Description
No. Min Actual Max
4-11 Frequency Range Test
High End of Band: 512-1024 MHz 550.0 MHz ______
256-512 MHz 550.0 MHz ______
128-256 MHz 275.0 MHz ______
64-128 MHz 137.5 MHz ______
32-64 MHz 68.70 MHz ______
16-32 MHz 34.30 MHz ______
8-16 MHz 17.10 MHz ______
4-8 MHz 8.500 MHz ______
2-4 MHz 4.200 MHz ______
1-2 MHz 2.100 MHz ______
0.5-1MHz 1.070 MHz ______
Low End of Band: 512-1024 MHz 230.0 MHz
256-512 MHz ______ 230.0 MHz
128-256 MHz ______ 115.0 MHz
64-128 MHz ______ 57.50 MHz
32-64 MHz ______ 28.80 MHz
16-32 MHz ______ 14.40 MHz
8-16 MHz ______ 7.200 MHz
4-8 MHz ______ 3.600 MHz
2-4 MHz ______ 1.800 MHz
1-2 MHz ______ 0.900 MHz
0.5-1 MHz ______ 0.450 MHz
4-12 Frequency Accuracy and
Fine Tune Test
Counter Readings, Difference: 110 Hz
X10 110 Hz
TIME BASE VERN, not-CAL, cw 1 kHz ______
TIME BASE VERN, not-CAL, ccw 1 kHz ______
FINE TUNE 10 kHz ______
4-13 Frequency Stability vs Time and
Restabilization Time Test
Time _______ 500 Hz
After frequency change _______ 500 Hz
After band change _______ 250 Hz
After RF ON/OFF set to ON _______ 500 Hz
