Model 8640B TM 9-4935-601-14-7&P
Table 4-1. Performance Test Record (2 of 8)
Results
Para Test Description
No. Min Actual Max
4-14 Frequency Stability vs Temperature
Test ______ 50 kHz
4-15 Frequency Stability vs Line Voltage
Test
+5% to -10% Line Voltage ______ 50 Hz
4-16 Frequency Stability Test
(Load) ______ 50 Hz
(Level) ______ 50 Hz
(Mode): 10 kHz ______ 200 Hz
20 kHz ______ 200 Hz
40 kHz ______ 400 Hz
80 kHz ______ 800 Hz
160 kHz ______ 1.6 kHz
320 kHz ______ 3.2 kHz
640 kHz ______ 6.4 kHz
1.28 MHz ______ 12.8 kHz
2.56 MHz ______ 25.6 kHz
4-17 Harmonics Test
Frequency Range: 0.5-1 MHz 35 dB ______
1-2 MHz 35 dB ______
2-4 MHz 35 dB ______
4-8 MHz 35 dB ______
8-16 MHz 35 dB ______
16-32 MHz 35 dB ______
32-64 MHz 35 dB ______
64-128 MHz 35 dB ______
128-256 MHz 30 dB ______
256-512 MHz 30 dB ______
4-18 Sub-Harmonics and Non-Harmonic
Spurious Test
Below carrier 100 dB ______
4-19 Single Sideband Phase Noise Test
At 550 MHz >112 dB down 12 dB ______
At 450 MHz >120 dB down 20 dB ______
4-20 Single Sideband Broadband Noise
Floor Test
>140 dB down 30 dB _______
4-78
