Model 8640B TM 9-4935-601-14-7&P
PERFORMANCE TESTS
4-17. HARMONICS TEST (Cont'd)
NOTE
On bands 8 - 16 MHz and above, check for harmonics while tuning down in frequency. For
frequencies above 500 MHz, tune analyzer to observe second harmonic.
Spectrum Analyzer Signal Generator
Resolution Bandwidth Freq. Span Per Division Range Harmonics Down
100 kHz 1 MHz 1-2 MHz >35 dB____________
100 kHz 2 MHz 2-4 MHz >35 dB____________
100 kHz 5 MHz 4-8 MHz >35 dB____________
300 kHz 10 MHz 8-16 MHz >35 dB____________
300 kHz 20 MHz 16-32 MHz >35 dB____________
300 kHz 50 MHz 32-64 MHz >35 dB____________
300 kHz 100 MHz 64-128 MHz >35 dB____________
300 kHz 100 MHz 128-256 MHz >30 dB____________
300 kHz 100 MHz 256-512 MHz >30 dB____________
4-18. SUB-HARMONICS AND NON-HARMONIC SPURIOUS TEST
SPECIFICATION:
Sub-Harmonics and Non-Harmonic Spurious: (excluding frequencies within 15 kHz of carrier whose effects are specified
under Residual AM and FM) >100 dB below carrier.
DESCRIPTION:
A notch filter is used to remove the fundamental. All non-harmonic spurious and sub-harmonics are then amplified and
measured with a spectrum analyzer.
4-13
