Model 8640B TM 9-4935-601-14-7&P
Table 4-1. Performance Test Record (6 of 8)
Results
Para Test Description
No. Min Actual Max
4-35 Peak Incidental Phase Modulation Test
512 MHz ______ +17.20
128 MHz ______ +8.60
4-36 Pulse Modulation Test
0.5-1 MHz Rise Time ______ 9 µs
Fall Time ______ 9 µs
Level Accuracy 5.4 div ______ 6.7 div
1-2 MHz Rise Time ______ 4 µs
Fall Time ______ 4 µs
Level Accuracy 5.4 div ______ 6.7 div
2-4 MHz Rise Time ______ 2 µs
Fall Time ______ 2 µs
Level Accuracy 5.4 div ______ 6.7 div
4-8 MHz Rise Time ______ 2 µs
Fall Time ______ 2 µs
Level Accuracy 5.4 div ______ 6.7 div
8-16 MHzRise Time ______ 1 µs
Fall Time ______ 1 µs
Level Accuracy 5.4 div ______ 6.7 div
16-32 MHz Rise Time ______ 1 µs
Fall Time ______ 1 µs
Level Accuracy 5.4 div ______ 6.7 div
32-64 MHz Rise Time ______ 1 µs
Fall Time ______ I1 s
Level Accuracy 5.4 div ______ 6.7 div
64-128 MHz Rise Time ______ 1 µs
Fall Time ______ 1 ,µs
Level Accuracy 5.4 div ______ 6.7 div
128-256 MHz Rise Time ______ 1 µs
Fall Time ______ 1 µs
Level Accuracy 5.4 div ______ 6.7 div
256-512 MHz Rise Time ______ 1 µs
Fall Time ______ 1 µs
Level Accuracy 5.4 div ______ 6.7 div
4-37 Pulse ON/OFF Ratio Test
Frequency Range: 256-512 MHz 40 dB ______
128-256 MHz 40 dB ______
64-128 MHz 40 dB ______
32-64 MHz 40 dB ______
16-32 MHz 40 dB ______
8-16 MHz 40 dB ______
4-8 MHz 40 dB ______
2-4 MHz 40 dB ______
1-2 MHz 40 dB ______
0.5-1 MHz 40 dB ______
4-82
