Model 8640B TM 9-4935-601-14-7&P
Table 4-1. Performance Test Record (5 of 8)
Results
Para Test Description
No. Min Actual Max
4-29 Output Leakage Test
0.5 to 400 MHz ______ -97 dBm
400 to 600 MHz ______ -97 dBm
600 to 1200 MHz ______ -97 dBm
4-30 Internal Modulation Oscillator Test
400 Hz Fixed: Frequency 392 Hz 408 Hz
Level (Standard) 1.0 Vrms ______
Level (Option 001) 3.0 Vrms ______
1 kHz Fixed: Frequency 980 Hz 1020 Hz
Level (Standard) 1.0 Vrms ______
Level (Option 001) 3.0 Vrms ______
Variable Frequency (Option 001) ______ +10%
4-31 Internal Modulation Oscillator
Distortion
Test (Option 001)
Variable: 20 Hz to 2 kHz ______ 0.5%
2 kHz to 600 kHz ______ 1.0%
Fixed: 400 Hz ______ 0.25%
1000 Hz ______ 0.25%
4-32 AM 3 dB Bandwidth Test
RANGE %AM Bandwidth
8-16 MHz 50% 0-60 kHz ______ 3 dB
90% 0-50 kHz ______ 3 dB
4-8 MHz 50% 0-30 kHz ______ 3 dB
90% 0-25 kHz ______ 3 dB
1-2 MHz 50% 0-20 kHz ______ 3 dB
90% 0-12.5 kHz ______ 3 dB
4-33 AM Distortion Test
50% ______ 1%
70% ______ 3%
90% ______ 3%
4-34 AM Sensitivity and Accuracy Test
External Sensitivity Accuracy: 171.0 mVrms ______ 189.0 mVrms
Indicated Accuracy: 90% 165.6 mVrms ______ 194.4 mVrms
70% 128.8 mVrms ______ 151.2 mVrms
50% 92.0 mVrms ______ 108.0 mVrms
30% (0-10) 55.2 mVrms ______ 64.8 mVrms
30% (0-3) 54.6 mVrms ______ 65.4 mVrms
20% 36.4 mVrms ______ 43.6 mVrms
10% 18.2 mVrms ______ 21.8 mVrms
4-81
