Model 8640B TM 9-4935-601-14-7&P
Table 4-1. Performance Test Record (4 of 8)
Results
Para Test Description
No. Min Actual Max
4-24 Output Level Accuracy Test
(Complete) (Cont'd)
Output Level Meter Reading
1 step ccw +13 dBm +11.5 dBm ______ +14.5 dBm
1 step ccw +8 dBm +6.5 dBm ______ +9.5 dBm
1 step ccw +3 dBm +1.5 dBm ______ +4.5 dBm
1 step ccw -5 dBm -7.0 dBm ______ -3.0 dBm
2 steps ccw +3 dBm +1.5 dBm ______ +4.5 dBm
3 steps ccw -7 dBm -8.5 dBm ______ -5.5 dBm
-17 dBm -472.0 mVdc ______ -529.6 mVdc
-27 dBm -472.0 mVdc ______ -529.6 mVdc
-37 dBm -472.0 mVdc ______ -529.6 mVdc
-47 dBm -472.0 mVdc ______ -529.6 mVdc
-57 dBm -445.6 mVdc ______ -561.0 mVdc
-67 dBm -445.6 mVdc ______ -561.0 mVdc
-77 dBm -445.6 mVdc ______ -561.0 mVdc
-87 dBm -445.6 mVdc ______ -561.0 mVdc
-107 dBm -445.6 mVdc ______ -561.0 mVdc
-117 dBm -445.6 mVdc ______ -561.0 mVdc
-127 dBm -445.6 mVdc ______ -561.0 mVdc
-137 dBm -445.6 mVdc ______ -561.0 mVdc
0.013 µV
(-144.75 dBm) -546.9 mVdc ______ -772.5 mVdc
4-25 Output Level Flatness Test ______ 0.5 dB
4-26 Output Impedance Test (In Band)
______ 100 mV
______ 13 mV
______ 6.5 mV
4-27 Output Impedance Test (Out of Band)
VSWR <2.0:1 9.5 dB ______
Return Loss 9.5 dB ______
VSWR <1.3:1 17.7 dB ______
Return Loss 17.7 dB ______
4-28 Auxiliary Output Test -5 dBm ______
4-80
