Model 8640B TM 9-4935-601-14-7&P
Table. 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
CHASSIS PARTS
C1 0180-2530 2 CAPACITOR-FXD 3900UF+75-10% 50VDC AL 56289 36D392GO50SV2B
C2 0180-2530 CAPACITOR-FXD 3900UF+75-10% 50VDC AL 56289 36D392GO50AC2B
C3 0180-2334 1 CAPACITOR-FXD 3900UF+75-10% 75VDC AL 56289 36D392F075BB2B
C4 0180-2277 2 CAPACITOR-FXD 8200UF+75-10% 25VDC AL 56289 36D822G025AC2A
C5 0180-2277 CAPACITOR-FXD 8200UF+75-10% 25VDC AL 56289 36D822G025AC2A
C6† 0160-4048 1 CAPACITOR FXD .022UF +20% 250WVAC MET C0633 PME 271 M 522
DS1 2140-0244 1 LAMP-GLOW A1H 135/105VDC 1MA T-2-BULB 08806 A1H
F1 2110-0002 1 FUSE 2A 250V 1.25X.25 UL IEC 71400 AGC-2
(FOR 100/120V OPERATION)
F1 2110-0094 1 FUSE 1.25A 250V 1.25X.25 UL IEC 75915 3121.25
(FOR 220/240V OPERATION)
J1 08640-60103 1 CONNECTOR, TYPE N RF OUTPUT(SEE FIG 6-2) 28480 08640-60103
M1† 1120-0539 1 METER 28480 1120-0539
0360 0053 1 TERMINAL-LUG-SLDR 10 SCR .204/.094 ID 83330 1410-10
MP1 0340-0486 1 INSULATOR-COVER TO- 3.33-THK 0011J A22-2003
MP2 0370-2376 1 KNOB:BAR, SKIRTED 0.250" OIA SHAFT 28480 0370-2376
FREQUENCY RANGE
MP3 0370-2378 1 KNOB:RNO, CONCENTRIC 0.125" DIA SHAFT 28480 0370-2378
(FM)
MP4 0370-2379 1 KNOB:RND, CONCENTRIC 0.125" DIA SHAFT 28480 0370-2379
(AM)
MP5 0370-2380 1 KNOB:BAR BASE 0.250" DIA SHAFT 28480 0370-2380
PEAK DEVIATION RANGE
MP6 0370-2381 1 KNOB:BAR BASE 0.250" DIA SHAFT 28480 0370-2381
(OPT 001) AUD OUT 3V
MP7 0370-2382 1 KNOB:RND, SKIRTED 0.250” DIA SHAFT 28480 0370-2382
(STANDARD) MCD FREQ
MP8 0370-2383 1 KNOB-BASE-PTR .375 IN JGK MGP-DECAL 28480 0370-2383
FINE TUNE
MP9† 0370-2387 1 KNOB:RND BASE 0.250" DIA SHAFT 28480 0370-2387
(STANDARD) AUD OUT 1V
MP10 0370-2445 1 KNOB-BASE-RND .5 IN JGK MGP-DECAL 28480 0370-2445
OUTPUT LEVEL VERNIER
MP11 0370-2446 1 KNOB-CONC-RND .5 IN JGK MGP-DECAL 28480 0370-2446
(OPT 001) MOO FREQ VERNIER
MP12 0403-0026 GLIDE:NYLCN 28480 0403-0026
MP13 0590-1011 1 NUT-KNRLD-R 15/32-32-THD .12-THK .61-WD 28480 0590-1011
MP14 1400-0825 1 CLIP-LED MTG 0.201-IN ID; 0.330-IN 00 28480 1400-0825
MP15 1540*0034 1 CONTAINER-PLASTIC POLYSTY 1.062LG 28480 1540-0034
MP16 08640-20163 1 CLAMP, CAP 28480 08640-20163
MP17 3150-0203 1 FILTER-CARTRIDGE EXP AL 3.6-W 6-L 28480 3150-0203
MP18 5001-0135 1 WRENCH:COMB 28480 5001-0135
MP19 5060-0109 1 CGNNECTOR:15 CONTACTS 28480 5060-0109
MP20† 08640-00063 1 PANEL, FRONT 28480 08640-00063
MP21 08640-00021 1 SHIELD. FM AMPLIFIER 28480 08640-00021
MP22† 08640-40044 1 SCREW, METER ZERO 28480 08640-40044
MP23 08640-00022 1 SUPPORT, PC BOARD 28480 08640-00022
MP24 08640-00030 1 SUPPORT, MODULE 28480 08640-00030
MP25 08640-00058 1 INSULATOR COUNTER 28480 08640-00058
MP26 08640-00059 1 INSULATOR, CONNECTOR 28480 08640-00059
MP27 08640-20078 1 EXTRUSION, TOP 28480 08640-20078
MP28 08640-20079 1 EXTRUSION, BOTTOM 28480 08640-20079
MP29 1500-0433 1 COUPLER, SHAFT 99934 A-201-34A
MP30 08640-20204 1 FRONT CASTING, 5H FM 28480 08640-20204
MP31 08640-40016 1 CLAMP. METER 28480 08640-40016
MP32 08640-40026 1 KNOB/DIAL ASSY, OUTPUT LEVEL 28480 08640-40026
MP33 08640 40046 1 LENS. DIFFUSING 28480 08640-40046
MP34 08640-40047 1 KNOB/DIAL ASSY(OPT 001)MOD FREQ RANGE 28480 08640-40047
MP35 08640-40049 1 WINDOW, FRONT 28480 08640-40049
MP36 08640 20296 1 DIAL GEAR ASSY,(OPT 001) 28480 08640-20296
MOD FRED. VERNIER SKIRT
MP37 08640-40055 1 KNOB & SKIRT, FREQUENCY TUNE 28480 08640-40055
MP38 08640-40056 1 SKIRT, OUTPUT LEVEL CURSOR 28480 08640-40056
MP39 08640-60036 1 BOARD ASSY, EXTENDER 28480 08640-60036
MP40 5040-0388 1 BUTTON, X10% 28480 5040-0388
MP41 5040-0389 1 BUTTON, K/MHZ 28480 5040-0389
MP42 5040-0390 1 BUTTON, VOLTS 28480 5040-0390
MP43 3030-0007 2 SCREW,SET 4-40(FRONT PANEL KNOBS) 28480 3030-0007
MP44 0624-0267 1 SCREWTPG 6=20 .625-IN-LG PAN-HD 28480 0624-0267
MP45 0626-0002 1 SCREW-TPG 6-20 .5-IN-LG PAN-HD SLT-REC 28480 0626-0002
MP46 1200-0043 1 INSULATOR-XSTR TO-3 02-THK 76530 322047
See introduction to this section for ordering information.
† SEE TABLES 7-1 AND 7-2, FOR BACKDATING
6-38
