Model 8640B TM 9-4935-601-14-7&P
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A26A2Q1 1854 0221 3 TRANSISTOR-DUAL NPN PO=75OMW 28480 1854-0221
A26A2Q2† 1854-0404 4 TRANSISTOR NPN SI TO-18 PD-360MW 28480 1854-0404
A26A2Q3† 1853-0034 6 TRANSISTOR PNP SI TO-18 PD-360MW 28480 1853-0034
A26A2Q4† 1853-0034 TRANSISTOR PNP SI TO-18 PD-360MW 28480 1853-0034
A26A2Q5† 1854-0404 TRANSISTOR NPN SI TO-18 PD-360MW 28480 1854=0404
A26A2Q6† 1854-0404 TRANSISTOR NPN SI TO-18 PD-360MW 28480 1854-0404
A26A2Q7† 1854-0404 TRANSISTOR NPN SI TO-18 PD-360MW 28480 1854-0404
A26A2Q8† 1853-0034 TRANSISTOR PNP S1 TO-18 PD-360MW 28480 1853-0034
A26A2Q9† 1853-0034 TRANSISTOR PNP SI TO-18 PD-360MW 28480 1853-0034
A26A2R1 0757-0465 RESISTOR 100K 1% .125W F TC=-0+-100 24546 C4-1/8-TO-1003-F
A26A2R2 0757-0440 4 RESISTOR 7.5K 1% .125W F TC=0+-100 24546 C4-1/8-TO-7501-F
A26A2R3 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-18-TO-1002-F
A26A2R4 0757-0442 RESISTOR 10K 1% .125W F TC= 0+ 100 24546 C4-1/8-TO-1002-F
A26A2R5 0698-3155 RESISTOR 4.64K 1% .125W F TC=0+-100 16299 C4-1/8-TO-4641-F
A26A2R6 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A26A2R7 0757-0440 RESISTOR 7.5K 1% .125W F TC=0+-100 24546 C4-1/8-TO-7501-F
A26A2R8 0757-0422 1 RESISTOR 909 1% .125W F TC=0+-100 24546 C4-1/8-TO-909R-F
A26A2R9 0757-0421 RESISTOR 825 1%.125W F TC=0+-100 24546 C4-1/8-TO-825R-F
A26A2R10 0757-0439 1 RESISTOR 6.81K 1% .125W F TC=0+-100 24546 C4-1/8-TO-6811-F
A26A2R11 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A26A2R12 0757-0442 RESISTOR 10K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1002-F
A26A2R13 0757-0401 RESISTOR 100 1% .125W F TC=0+-100 24546 C4-1/8TO-101-F
A26A2R14 0757-0421 RESISTOR 825 1% .125W F TC=0+-100 24546 C4-1/8-TO-825R-F
A26A2R15 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A26A2R16 0757-0280 RESISTOR 1K 1%.125W F TC-=0+-100 24546 C4-1/8-TO-1001F
A26A2R17 0698-3440 RESISTOR 196 1% .125W F TC=0+-100 16299 C4-1/8-T-196R-F
A26A2R18 0757-0438 RESISTOR 5.11K 1%.125W F TC=0+-100 24546 C4-18-TO-5111-F
A26A2R19 2100-2413 1 RESISTOR-TRMR 200 10% C SIDE-ADJ 1-TURN 30983 ETSOX201
A26A2R20 0698-3157 1 RESISTOR 19.6K 1% 125W F TC=0+-100 16299 C4-1/8-TO-1962-F
A26A2R21 0757-0416 RESISTOR 511 1% .125W F TC=0+-100 24546 C4-1/8-TO-51R1-F
A26A2R22 0757-0394 2 RESISTOR 51.1 1% .125W F TC=0+-100 24546 C4-1/8-TO-51RL-F
A26A2R23 0698-3162 3 RESISTOR 46.4K 1% .125W F TC=0+-100 16299 C4-1/8-TO-4642-F
A26A2R24 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO.-5111-F
A26A2R25 0698-3162 RESISTOR 46.4K 1%.125W F TC=0+-100 16299 C4-1/8-TO-4642-F
A26A2R26 07s7-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A26A2R27 0698-0085 RESISTOR 2.61K 1% .125w F TC=0+-100 16299 C4-1/8-TO-2611-F
A26A2R28 0698-3162 RESISTOR 46.4K 1% .125W F TC=0+-100 16299 C4-1/8-TO-4642-F
A26A2R29 0698-3150 RESISTOR 2.37K 1% .125W F TC=0+-100 16299 C4-1/8-TO-2371-F
A26A2R30 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A26A2R31 0698-3154 RESISTOR 4.22K 1% .125W F TC-=0+-100 16299 C4-1/8-TO-0221-F
A26A2R32 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A26A2R33 0698-3450 RESISTOR 42.2K 1% .125W F TC=0+-100 16299 C4-1/8-TO-4222-F
A26A2R34 0757-0289 2 RESISTOR 13.3K 1% .125w F TC=0+-100 19701 MF4C1/8-TO-1332-F
A26A2R35 0698-0082 1 RESISTOR 464 1% .125W F TC=0+-100 16299 C4-1/8-TO-4640-F
A26A2R36 0698-0083 RESISTOR 1.96K 1% .125W F TC=0+-100 16299 C4-1/8-TO-1961-F
A26A2R37 0757-0442 RESISTOR 10K 1% .125W F TC-=0+-100 24546 C4-1/8-TO-1002-F
A26A2R38 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A26A2R39 0698-0083 RESISTOR 1.96K 1% .125W F TC=0+-100 16299 C4-1/8-TO-1961-F
A26A2TP1 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A26A2TP2 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A26A2TP3 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A26A2TP4 0360-1514 TERMINAL-STUD SGL-PIN PRESS-YTG 28480 0360-1514
A26A2TP5 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A26A2TP6 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A26A2TP7 0360-1514 TERMINAL-STUD SGL-PIN PRESS-HTG 28480 0360-1514
A26A2TP8 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A26A2U1† 1826-0114 1 IC UA 710 CCMPARATOR 07263 710HM
A26A2U2† 1820-0448 1 IC:TTL QUAD 2-INPT NAND GATE 01295 SN5400N
A26A2U3 1820-0579 1 IC SN74 123 N MV 01295 SN74123N
A26A2VR1 1902-3139 1 OIODE-2NR 8.25V 5% DO-7 PD=.4W TC-+.053% 04713 SZ 10939-158
A26A3 08640-60016 1 MODULATOR ASSY 28480 08640-60016
A26A3C1 0160-3094 CAPACITOR-FXD .1UF+-10% 100WVDC CER 28480 0160-3094
A26A3C2 0160-3094 CAPACITOR-FXD .1UF +-10% 100WVDC CER 28480 0160-3094
A26A3C3 0150-0048 4 CAPACITOR-FXD .22PF +-5% 500WVDC TI DIOX 95121 TYPE QC
1251-2229 8 CONNECTOR-SGL CONT SKT .033-DIA 00779 1-331677-3
A26A3C4 0150-0048 CAPACITOR-FXD .22PF -5% 500WVDC TI DIOX 95121 TYPE OC
1251-2229 CONNECTOR-SGL CONT SKT .033-DIA 00779 1-331677-3
A2643C5 0150-0048 CAPACITOR-FXD .22PF +- 5% 500WVDC TI DIOX 95121 TYPE QC
1251-2229 CONNECTOR-SGL CONT SKT .033-DIA 00779 1-331677-3
A26A3C6 0150-0048 CAPACITOR-FXD .22PF +-5% 500VDC TI DIOX 95121 TYPE QC
1251-2229 CONNECTOR-SGL CONT SKT .033-DIA 00779 1-331677-3
A26A3CR1 08640-60163 1 MATCHED DIODE SET 28480 08640-60163
(INCLUDES A26A3CR2 THRU 8, NSR)
A26A3CR2 NSR, PART OF A26A3CR1.
A26A3CR3 NSR, PART OF A26A3CR1.
A26A3CR4 NSR, PART OF A26A3CR1.
See introduction to this section for ordering information.
† SEE TABLES 7-1 AND 7-2, FOR BACKDATING
6-35
