Model 8640B TM 9-4935-601-14-7&P
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A10A1J1 1250-1220 CONNECTOR-RF SMC N PC 98291 50-051-0109
A10A1J2 1250-1220 CONNECTOR-RF SMC M PC 98291 50-051-0109
A10A1J3 1250-1220 CONNECTOR-RF SMC M PC 98291 50-051-0109
A10A1J4 1250-1220 CONNECTOR-RF SMC M PC 98291 50-051-0109
A10A1K1 0490-1073 RELAY-RFED 1A 250MA 120VAC 4.5VDC-COIL 28480 0490-1073
A10A1K2 0490-1073 RELAY-RFED 1A 250MA 120VAC 4.5VDC-COIL 28480 0490-1073
A10A1K3 0490-1073 RELAY-RFED 1A 250MA 120VAC 4.5VDC-COIL 28480 0490-1073
A10A1K4 0490-1073 RELAY-RFED 1A 250MA 120VAC 4.5VDC-COIL 28480 0490-1073
A10A1L1 9100-3375 2 COIL-FXD MOLDED RF CHOKE .462UH 5% 28480 9100-3375
A10A1L2 9100-3365 2 COIL-FXD MOLDED RF CHOKE .5UH 5% 0004A AE-.500J-P
A10A1L3 9100-3375 COIL-FXD MOLDED RF CHOKE .462UH 5% 28480 9100-3375
A10A1L4 9100-3361 2 COIL-FXD MOLDED RF CHOKE .3UH 5% 28480 9100-3361
A10A1L5 9100-3362 1 COIL-FXD MOLDED RF CHOKE .323UH 5% 0004A AD.323J-P
A10A1L6 9100-3361 COIL-FXD MOLDED RF CHOKE .3UH 5% 28480 9100-3361
A10A1L7 9100-3364 1 COIL-FXD MOLDED RF CHOKE 8UH 5% 0004 AH-B.00J-I
A10A1L8 9100-3374 2 COIL-FXD MOLDED RF CHOKE 4UH 5% 28480 9100-3374
A10A1L9 9100-3363 1 COIL-FXD MOLDED RF CHOKE 4.74UH 5% 0004A AK-4.74J-P
A10A1L10 9100-3369 Z COIL-FXD MOLDED RF CHOKE .924UH 5% 28480 9100-3369
A10A1L11 9100-3370 3 COIL-FXD MOLDED RF CHOKE 1UH 5% 28480 9100-3370
A10A1L12 9100-3369 COIL-FXD MOLDED RF CHOKE .924UH 5% 28480 9100-3369
A10A1L13 9100-3368 2 COIL-FXD MOLDED RF CHOKE .6UH 5% 28480 9100-3368
A10A1L14 9100-3367 1 COIL-FXD MOLDED RF CHOKE .646UH 5% 0004A AC-.646J-P
A10A1L15 9100-3368 COIL-FXD MOLDED RF CHOKE .6UH 5% 28480 9100-3368
A10A1L16 9100-3374 COIL-FXD MOLDED RF CHOKE 4UH 5% 28480 9100-3374
A10A1L17 9100-3372 2 COIL-FXD MOLDED RF CHOKE 2UH 5% 28480 9100-3372
A10A1L18 9100-3373 1 COIL-FXD MOLDED RF CHOKE 2.37UH 5% 28480 9100-3373
A10A1L19 9100-3359 2 COIL-FXD MOLDED RF CHOKE .231UH 5% 0004A AC-.231J-P
A10A1L20 9100-3360 1 COIL-FXD MOLDED RF CHOKE .25UH 5% 0004A AC-.250J-P
A10A1L21 9100-3359 COIL-FXD MOLDED RF CHOKE .231UH 5% 0004A AC-.231J-P
A10A1L22 9100-3357 2 COIL-FXD MOLDED RF CHOKE .15UH 5s 0004A AC-.150J-P
A10A1L23 9100-3358 1 COIL-FXD MOLDED RF CHOKE .162UH 5% 0004A AC-.162J-P
A10A1L24 9100-3357 COIL-FXD MOLDED RF CHOKE .15UH 5% 0004A AC-.150J-P
A10A1L25 9100-3372 COIL-FXD MOLDED RF CHOKE 2UH 5% 28480 9100-3372
A10A1L26 9100-3370 COIL-FXD MOLDED RF CHOKE 1UH 5% 28480 9100-3370
A10A1L27 9100-3371 1 COIL-FXD MOLDED RF CHOKE 1.18UH 5% 28480 9100-3371
A10A1L28 9100-3355 2 COIL-FXD MOLDED RF CHOKE .115UH 5 0004A AC-.105J-P
A10A1L29 9100-3356 1 COIL-FXD MOLDED RF CHOKE .125UH 5% 0004A AC-.125J-P
A10A1L30 9100-3355 COIL-FXD MOLDED RF CHOKE .115UH 5 0004A AC-.115J-P
A10A1L31 9100-3513 3 COIL-FXD NON-MOLDED RF CHOKE 7 5UH 24226 8123-2
A10A1L32 9100-3513 COIL-FXD NON-MOLDED RF CHOKE 7 5UH 24226 8123-2
A10A1L33 9100-3513 COIL-FXD NON-MOLDED RF CHOKE 7 5UH 24226 8123-2
A10A1L34 9100-3370 COIL-FXD MOLDED RF CHOKE 1UH 5% 28480 9100-3370
A10A1L35 9100-3365 COIL-FXD MOLDED RF CHOKE .5UH 5% 0004A AE-500J-P
A10A1L36 9100-3366 1 COIL-FXD MOLDED RF CHOKE .592UH 5% 0004A AE-592J-P
A10A1L37 9100-3512 3 COIL-FXD NON-MOLDED RF CHOKE 50UH 24226 8123-1
A10A1L38 9100-3512 COIL-FXD NON-MOLDED RF CHOKE 50UH 24226 8123-1
A10A1L39 9100-3512 COIL-FXD NON-MOLDED RF CHOKE 50UH 24226 8123-1
A10A1L40 9100-3514 6 COIL-FXD NON-MOLDED RF CHOKE 30UH 24226 8123-3
A10A1L41 9100-3514 COIL-FXD NON-MOLDED RF CHOKE 30UH 24226 8123-3
A10A1L42 9100-3514 COIL-FXD NON-MOLDED RF CHOKE 30UH 24228 8123-3
A10A1L43 9100-3514 COIL-FXD NON-MOLDED RF CHOKE 30UH 24226 8123-3
A10A1L44 9100-3514 COIL-FXD NON-MOLDED RF CHOKE 30UH 24226 8123-3
A10A1L45 9100-3514 COIL-FXD NON-MOLDED RF CHOKE 30UH 24226 8123-3
A10A1L46 PART OF ETCHED CIRCUIT BOARD
A10A1L47 PART OF ETCHED CIRCUIT BOARD
A10A1L48 PART OF ETCHED CIRCUIT BOARD
A10A1L49 9140-0144 2 COIL-FXD MOLDED RF CHOKE 4.7UH 10% 24226 10/471
A10A1L50 9140-0144 COIL-FXD MOLDED RF CHOKE 4.7UH 10% 24226 10/471
A10A1L51 08640-80001 FILTER, TOROID 28480 08640-80001
A10A1L52 08640-80001 FILTER, TOROID 28480 08640-80001
A10A1L53 08640-80001 FILTER, TOROID 28480 08640-80001
A10A1L54 08640-80001 FILTER, TOROID 28480 08640-80001
A10A1MP1 1480-0352 1 PIN:DETENT 0.055 X 0.750- DIA 00000 1480-0352
A10A1MP2 08443-20003 1 ROLLER, DETENT 28480 08443-20003
A10A1MP3 08640-00029 1 SPRING, DETENT 28480 08640-00029
A10A1MP4 08640-20082 1 SHAFT, CAM 28480 08640-20082
A10A1MP5 08640-20083 1 SHAFT, CAN FOLL 28480 08640-20083
A10A1MP6 08640-20200 1 CAST, BOTTOM COVER, D/F 28480 08640-20200
A10A1MP7 08640-20214 1 BUSHING, CAM HOUSING 28480 08640-20214
A10A1MP8 08640-20219 1 COVER, CAM 28480 08640-20219
A10A1MP9 08640-40004 1 FOLLOWER, CAN 28480 08640-40004
A10A1MP10 08640-20064 1 CAM, SLIDER 28480 08640-20064
A10A1MP11 2200-0105 SCREWIMACH 4-40 .312-IN-LG PAN-HD-POZI 28480 2200-0105
A10A1MP12 08640-20133 1 SUPPORT, CLAMP 28480 08640-20133
A10A1MP16 3030-0007 SCREW-SET 4-40 .125-IN-L SMALL CUP-PT 28480 3030-0007
A10A1MP14 2200-0145 1 SCREW,-MACH 4-40 438-IN-LG PAN-HD-POZI 28480 2200-0145
A10A1MP15 08640-20206 1 RETAINER, SLIDER 28480 08640-20206
See introduction for ordering information
†SEE TABLES 7-1 AND 7-2, FOR BACKDATING.
6-20
