Model 8640B TM 9-4935-601-14-7&P
Table. 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A10A2C46 0180 1743 CAPACITOR-FXD .1UF+-10% 35VDC TA 56289 150D104X9035A2
A10A2C47 0180-1743 CAPACITOR-FXD .1UF+-10% 35VDC TA 56289 150D104X9035A2
A10A2C48 0180-1743 CAPACITOR-FXD .1UF+-10% 35VDC TA 56289 150D104X9035A2
A10A2C49 0180-1743 CAPACITOR-FXD .1UF+-10% 35VDC TA 56289 1500104X9035A2
A10A2C50 0180-1743 CAPACITOR-FXD .1UF+-10% 35VDC TA 56289 150D104X9035A2
A10A2C51 0160-3456 CAPACITOR-FXD 1000PF +-10% 1000WVDC CER 28480 0160-3456
A10A2C52 0180-0197 CAPACITOR-FXD 2.2UF+-10% 20VDC TA 56289 150D225X9020A2
A10A2CR1 1901-0025 OIODE-GEN PRP 100V 200MA DO-7 28480 1901-0025
A10A2CR2 1901-0025 DIODE-GEN PRP 100V 200MA DO-7 28480 1901-0025
A10A2CR3 1901-0025 CIODE-GEN PRP 100V 200MA DO-7 28480 1901-0025
A10A2CR4 1901-0025 OIODE-GEN PRP 100V 200MA DO-7 28480 1901-0025
A10A2CR5 1901-0025 OIODE-GEN PRP 100V 200MA DO-7 28480 1901-0025
A10A2CR6 1901-0025 OIODE-GEN PRP 100V 200MA DO-7 28480 1901-0025
A10A2CR7 1901-0025 DIODE-GEN PRP 100V 200MA DO-7 28480 1901-0025
A10A2CR8 1901-0025 DIODE-GEN PRP 100V 200MA DO-7 28480 1901-0025
A1OA2CR9 1901-0025 DIODE-GEN PRP 100V 200MA DO-7 28480 1901-0025
A10A2L1 PART OF ETCHED CIRCUIT BOARD
A10A2L2 NOT ASSIGNED
A10A2L3 9100 1620 COIL-FXD MOLDED RF CHOKE 15UH 10% 24226 15/152
A10A2L4 9140-0096 1 COIL-FXD MOLDED RF CHOKE 1UH 10% 24226 15/101
A10A2L5 9100-1612 1 COIL-FXD MOLDED RF CHOKE .33UH 20% 24226 15/330
A10A2L6 9140-0094 1 COIL-FXD MOLDED RF CHOKE .68UH 10% 24226 15/680
A10A2L7 9100-1615 1 COIL-FXD MOLDED RF CHCKE 1.2UH 10% 24226 15/121
A10A2L8 9140-0098 1 COIL-FXD MOLDED RF CHOKE 2.2UH 10% 24226 15/221
A10A2L9 9100-1618 1 COIL-FXD MOLDED RF CHOKE 5.6UH 10% 24226 15/561
A10A2L10 9140-0114 1 COIL-FXD MOLDED RF CHOKE 10UH 10% 24226 15/102
A10A2L11 9100-1620 COIL-FXD MOLDED RF CHOKE 15UH 10% 24226 15/152
A10A2L12 9100-1620 COIL-FXD MOLDED RF CHOKE 15UH 10% 24226 15/152
A10A2L13 9100-1628 2 COIL-FXD MOLDED RF CHOKE 43UH 5% 24226 15/432
A10A2L14 9100-1620 COIL-FXD MOLDED RF CHOKE 15UH 10% 24226 15/152
A10A2L15 9100-1620 COIL-FXD MOLDED RF CHOKE 15UH 10% 24226 15/152
A10A2L16 9100-1628 COIL-FXD MOLDED RF CHOKE 43UH 5% 24226 15/432
A10A2Q1 1854-0071 TRANSISTOR NPN SI PDO300MW FT-200MHZ 28480 1854-0071
A10A2Q2 1853-0034 3 TRANSISTOR PNP SI TO-18 PD=360MW 28480 1853-0034
A10A2Q3 1853-0034 TRANSISTOR PNP SI TO-18 PD=360MW 28480 1853-0034
A10A2Q4 1853-0034 TRANSISTOR PNP SI TO-18 PD=360MW 28480 1853-0034
A10A2Q5 1854-0345 1 TRANSISTOR NPN 2N5179 SI TO-72 PD=200MM 04713 2N5179
A10A2R1 0757-0394 RESISTOR 51.1 1% .125W F TC=0+-100 24546 C4-1/8-TO-51R1-F
A10A2R2 0757 0394 RESISTOR 51.1 1% .125W F TC=0+-100 24546 C4-1/8-TO-51R1-F
A10A2R3 0757-0394 RESISTOR 51.1 1% .125W F TC=0+100 24546 C4-1/8-TO-51R1-F
A10A2R4 0757-0984 9 RESISTOR 10 1% .5W F TC=0+-100 19701 MF7C1/2TO-10R0-F
A10A2R5 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A10A2R6 0698-7194 3 RESISTOR 17.8 2% .05W F TC=0+-100 24546 C3-1/8-TO-17R8-G
A10A2R7 0698-7223 6 RESISTOR 287 2% .05W F TC=0+-100 24546 C3-1/8-TO-287R-G
A10A2R8 0698-7223 RESISTOR 287 2% .05W F TC=0+-100 24546 C3-1/8-TO-287R-G
A10A2R9 0757-0394 RESISTOR 51.1 1% .125W F TC=0+-100 24546 C4-1/8-TO-51Rl-F
A10A2R10 0757-0984 RESISTOR 10 1%.5W F TC=0+-100 19701 MF7C1/2-TO-10RO-F
A10A2R11 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A10A2R12 0698-7194 RESISTOR 17.8 2% .05W F TC=0+-100 24546 C3-1/8-TO-17R8-G
A10A2R13 0698-7223 RESISTOR 287 2% .05W F TC=0+-100 24546 C3-1/8-TO-287R-G
A10A2R14 0698-7223 RESISTOR 287 2%: .OSW F TC=0+-100 24546 C3-1/8-TO-287R-G
A10A2R15 0757-0394 RESISTOR 51.1 1% .125W F TC-0+-100 24546 C4-1/8-TO-51R1-F
A10A2R16 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-51R1-F
A10A2R17 0757-0984 RESISTOR 10 1% .5W F TC-0+-100 19701 MF7C1/2-TO-10RO-F
A10A2R18 0698-7194 RESISTOR 17.8 2% .05W F TC=0+100 24546 C3-I/8-TO-17RS8G
A10A2R19 0698-7223 RESISTOR 287 2% .O5 F TC=0+-100 24546 C3-1/8-TO-287R-G
A10A2R20 0698-7223 RESISTOR 287 2% .05W F TC=0+-100 24546 C3-1/8-TO-287R-G
A10A2R21 0757-0398 RESISTOR 75 1% .125W F TC=0+-100 24546 C4-1/8-TO-75RO-F
A10A2R22 0757-0984 RESISTOR 10 1% .5W F TC=0+-100 19701 MF7C1/2-TO-10R-F
A10A2R23 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A10A2R24 0698-7224 RESISTOR 316 2% .05W F TC=0+-100 24546 C3-1/8-TO-316R-G
A10A2R25 0698-7219 RESISTOR 196 2% .05W F TC=0+-100 24546 C3-1/8-TO-196R-G
A10A2R26 0698-7190 2 RESISTOR 12.1 2% .05W F TC=0+-100 24546 C3-1/8-TO-12R1-G
A10A2R27 0698-7227 4 RESISTOR 422 2% .05W F TC=0+-100 24546 C3-1/8-TO-422R-G
A10A2R28 0698-7227 RESISTOR 422 2% .05W F TC=0+-100 24546 C3-1/8-TO-422R-G
A10A2R29 0698-3437 RESISTOR 133 1% .125W F TC=0+-100 16299 C4-1/8-TO-133R-F
A10A2R30 0757-0399 RESISTOR 82.5 1% .125W F TC=0+=100 24546 C4-1/8-TO-82R5-F
A10A2R31 0757-0984 RESISTOR 10 1% .5W F TC=0+-100 19701 MF7C1/22TO-10RO-F
A10A2R32 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A10A2R33 0698-7224 RESISTOR 316 2% .05W F TC=0+-100 24546 C3-1/8-TO-316R-G
A10A2R34 0698-7219 RESISTOR 196 2% .05W F TC=0+-100 24546 C3-1/8-TO-196R-G
A10A2R35 0698-7190 RESISTOR 12.1 2% .05W F TC=0+-100 24546 C3-1/8-TO-12R1-G
A10A2R36 0698-7227 RESISTOR 422 2% .05W F TC=0+-100 24546 C3-1/8-TO-422R-G
A10A2R37 0698-7227 RESISTOR 422 2% .05W F TC=0+100 24546 C3-1/8-TO-422R-G
A1042R38 0757-0399 RESISTOR 82.5 1% .125W F TC=0+-100 24546 C4-1/8-TO-82R5-F
A10A2R39 0698-3437 RESISTOR 133 1% . .125W F TC=0+-100 16299 C4-1/8-TO-133R-F
A10A2R40 0757-0984 RESISTOR 10 1% .5W F TC0+-100 19701 MF7C1/2-TO 10RO-F
See introduction to this section for ordering information.
6-22
