TM 9-4935-601-14-7&P
Model 8640B
Table 6-3. Replaceable Parts
Reference HP Part Mfr
Designation Number Qty Description Code Mfr Part Number
A22Q1 1884-0012 THYRISTOR-SCR JEDEC 2N3528 02735 2N3528
A22Q2 1854-0039 TRANSISTOR NPN 2N3053 SI TO-5 PD=1W 04713 2N3053
1200-0173 INSULATOR XSTR TO-5 .075-THK 28480 1200-0173
A22Q3 1854-0039 TRANSISTOR NPN 2N3053 SI TO-5 PD=1W 04713 2N3053
1200-0173 INSULATOR-XSTR TO-5 .075-THK 28480 1200-0173
A22Q4 1884-0012 THYRISTOR-SCR JEDEC 2N3528 02735 2N3528
A22R1 0698-0085 3 RESISTOR 2.61K 1% .125W F TC=0+-100 16299 C4-1/8-TO-2611-F
A22R2 0757-0280 8 RESISTOR 1K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1001-F
A22R3 0698-3154 6 RESISTOR 4.22K 1% .125W F TC=00+100 16299 C4-1/8-TO-4221-F
A22R4 0757-0401 RESISTOR 100 1% .125W F TC=0+-100 24546 C4-1/8-TO-101-F
A22R5 0698-0084 2 RESISTOR 2.15K 1% 125W F TC=0+-100 16299 C4-1/8-TO-2151-F
A22R6 0698-3154 RESISTOR 4.22K 1% 125W F TC=0+-100 16299 C4-1/8-TO-4221-F
A22R7 2100-3123 RESISTOR-TRMR 500 10% C SIDE-ADJ 17-TURN 32997 3006P-1-501
A22R8 0683-0275 2 RESISTOR 2.7 5% .25W FC TC=-400/+500 01121 CB27G5
A22R9 0698-3439 2 RESISTOR 178 1% .125W F TC=+-100 16299 C4-1/8-TO-178R-F
A22R10 0757-0397 RESISTOR 68.1 1% .125W F TC=0+-100 24546 C4-1/8-TO-68R1-F
A22R11 0698-3447 RESISTOR 422 1% .125W F TC=0+-100 16299 C4-1/8-TO-4221-F
A22R12 0811-1668 2 RESISTOR 1..5 5% 2W PW TC=0+-400 75042 BWH2-1R5-J
A22R13 0757-0278 RESISTOR 1.78K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1781-F
A22R14 0698-0085 RESISTOR 2.61K 1% .125W F TC=0+-100 16299 C4-1/8-TO-2611-F
A22R15 0757-0280 RESISTOR 1K 1% .125W F TC=0+-100 24546 C4-1/8-TO-1001-F
A22R16 0698-3154 RESISTOR 4.22K 1% .125W F TC=0+-100 16299 C4-1/8-TO-4221-F
A22R17 0757-0401 RESISTOR 100 1% .125W F TC=0+-100 24546 C4-1/8-TO-101-F
A22R18 0757-0438 RESISTOR 5.11K 1% .125W F TC=0+-100 24546 C4-1/8-TO-5111-F
A22R19 2100-3123 RESISTOR-TRMR 500 10% C SIDE-ADJ 17-TURN 32997 3006P-1-501
A22R20 0698-0084 RESISTOR 2.15K 1% .125M F TC=0+-100 16299 C4-1/8-TO-2151-F
A22R21 0683-0275 RESISTOR 2.7 5% .25W FC TC=-400/+500 01121 CB27G5
A22R22 0698-3439 RESISTOR 178 1% .125W F TC=0+-100 16299 C4-1/8-TO-178R-F
A22R23 0757-0397 RESISTOR 68.1 1% .125W F TC=0+-0100 24546 C4-1/8-TO-68R1-F
A22R24 0698-3447 RESISTOR 422 1% .125W F TC=0+-100 16299 C4-1/8-TO-422R-F
A22R25 0811-1668 RESISTOR 1.5 5% 2W PW TC=0+-400 75042 BWH2-1R-J
A22R26 0698-7260 2 RESISTOR 10K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1002-G
A22R27 0698-7260 RESISTOR 10K 2% .05W F TC=0+-100 24546 C3-1/8-TO-1002-G
A22TP1 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A22TP2 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A22TP3 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A22TP4 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A22TP5 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A22TP6 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A22TP7 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A22TP8 0360-1514 TERMINAL-STUD SGL-PIN PRESS°MTG 28480 0360-1514
A22TP9 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A22TP10 0360-1514 TERMINAL-STUD SGL-PIN PRESS-MTG 28480 0360-1514
A22U1 1826-0010 IC UA 723 V RGLTR 07263 723HM
A22U2 1826-0010 IC UA 723 V RGLTR 07263 723HM
A22VR1 1902-0202 2 DIODE-ZNR 15V 5% DO-15 PD=1W TC=+.057% 28480 1902-0202
A22VR2 1902-3256 2 DIODE=ZNR 23.7V 5% DO-7 PD-.4W TC=+.076% 04713 SZ 10939-290
A22VR3 1902-0761 1 DIOOE-ZNR 1N821 6.2V 5% DO-7 PD.25W 04713 1N821
A22VR4 1902-0202 DIODE-ZNR 15V 5% DO-15 PD=1W TC=+.057% 28480 1902-0202
A22VR5 1902-3256 DIODE-ZNR 23.7V 5% DO-7 PD=.4W TC=+.076% 04713 SZ 10939-290
A22XF1A 1251-2313 CONNECTOR-SGL CONT SKT .04-DIA 00779 3-332070-5
A22XF1B 1251-2313 CONNECTOR-SGL CONT SKT .04-DIA 00779 3-332070-5
A22XF2A 1251-2313 CONNECTOR-SGL CONT SKT .04-DIA 00779 3-332070-5
A22XF2B 1251-2313 CONNECTOR-SGL CONT SKT .04-DIA 00779 3-332070-5
A23 NOT ASSIGNED
A24 08640-60007 1 SERIES REGULATOR SOCKET ASSY 28480 08640-60007
A24MP1 0361-0009 1 RIVET, SEMITUBULAR OVAL HD 0.188" LG 00000 OBD
A24MP2 0403-0152 I GUIDE-PC BD BLK POLYC .062-BD-THKNS 1-LG 28480 0403-0152
A24XQ1 1200-0041 4 SOCKET-XSTR 2-CONT TO-3-PKG 22753 PTS-1
A24XQ2 1200-0041 SOCKET-XSTR 2-CONT TO-3-PKG 22753 PTS-1
A24XQ3 1200-0041 SOCKET-XSTR 2-CONT TO-3-PKG 22753 PTS-1
A24XQ4 1200-0041 SOCKET-XSTR 2-CONT TO-3-PKG 22753 PTS-1
A25 NOT ASSIGNED
A26 08640-60110 1 AM/AGC AND RF AMPLIFIER ASSEMBLY 28480 08640-60110
A26C1 0160-2049 12 CAPACITOR-FXD 5000PF +80-20% 500WVDC CER 28480 0160-2049
A26C2 0160-2049 CAPACITOR-FXD 5000PF +80-20% 500WVDC CER 28480 0160-2049
A26C3 0160-3219 3 CAPACITOR-FXD 100PF +-20% 500WVDC CER 28480 0160-3219
A26C4 0160-3219 CAPACITOR-FXD 100PF +-20% 500WVDC CER 28480 0160-3219
A26C5 0160-2049 CAPACITOR-FXD 5000PF +80-20% 500WVDC CER 28480 0160-2049
See introduction to this section for ordering information
SEE TABLES 7-1 AND 7-2, FOR BACKDATING
6-32
