Model 8640B TM 9-4935-601-14-7&P
Table 1-2. Recommended Test Equipment (4 of 7)
Instrument Type Critical Specifications Suggested Model Use*
Frequency Counter Optional Digital Output: 1248 with 1 Option 003 P
(Cont'd) (on) state positive (compatible with
D/A Converter)
Function Generator Range: 0.1 Hz to 1 kHz HP 3300A P,A
Output Impedance: 600Ω
Output Level: >1 Vpk
FM Linearity Circuit See Figure 1-8 HP 08640-60503 A
Mixer (3 required) Double Balanced HP 10514A P,A
Range: 0.45 - 550 MHz
Noise Phase Lock See Figure 1-9 HP 08640-60504 P
Circuit
Oscilloscope 50 MHz Real Time HP 180A/1801A/ P,A,T
Sensitivity: 5 mV/division 1820C
Internal/External Sweep and
Triggering
Power Meter Range: 0.45 - 550 MHz HP 432A P,A,T
Input: -20 to +10 dBm
Accuracy: 1%
With Thermistor VSWR: <1.3:1 With HP 478A
Mount Option H63
Power Meter Range: 10 - 550 MHz HP 435A P,A
Input Level: -10 to +20 dBm
Accuracy: ±1% of reading
With Power Sensor VSWR: <1.18:1 With HP 8481A
(Thermocouple)
Pulse Generator Range: 50 Hz to 500 kHz HP 8003A P,T
Output: >1V into 50Ω
Pulse Width: down to 1 µs
Transition Time: <50 ns
Quartz Oscillator Output: 1 MHz (level compatible HP 105B P
with Frequency Counter)
Stability: <5 x 10
-18
/24 hours
<5 x 10
-12
/s
*P = Performance; A = Adjustments; T = Troubleshooting
1-16
